tarantula . Proc ess Max. dispensing speed (dots /h) Piezo Jet: > 720‘000 dots/h T ime/Pressur e: 28‘000 dots /h Solder Paste Jet: 720‘000 dots/h Archimedean Screw: 24‘000 dots/h Dispense mode Dot , line, curve, inter…
RELENTLESS ALL-
TERRAIN DISPENSER
Introducing – The Tarantula – Multitasking expert. State-
of-the-art technology with a wide range of applications.
l
Up to 3 valves simultaneously
l
5 different valves, large application range
l
Monitoring sizes & weight of dispense dots
l
Process control adjustment and dot stabilisation
l
Valve up to 720‘000 - System Ø 180‘000 dots/h
l
Up to 2‘000‘000 dots/h in line mode
l
PCB size 560 x 610 mm, optional 1’800 x 610 mm
l
Up to 80 mm programmable Z stroke (3.35”)
l
No vibration, symmetrical mineral casting
l
No warpage, no thermal drift
CELL SOLUTION
LINE SOLUTION
Integration in any line
l
Fast, reliable double drive linear motors
l
No maintenance, longest lifetime
dispense technology.
process control
.
productivity.
large dispense area.
mineral cast chassis.
linear motors.
MULTITALENT SOFTWARE AT YOUR FINGERTIPS State of the art, full graphics,
21.5” 16:9 touch screen, Windows - 64 bit, ingertip operation, real time visualiza-
tion zoom at camera windows, all-in-one job planning, universal CAD conversion,
setup optimization, easy deinition of pattern and guided process support
Valves & Pumps
Media Heating
Needle and jet heating system
Level Detection Automatic syringe level detection
Integrated Inspection 2D defect detection for dispensed material
Full process control meeting automotive standards and more, Adaptation & stabilisation,
Integration & datatransfer of existing pick-and-place machines as Diplan, UniCam,
Cogiscan etc., Vacuum Cleaning Station, High Precision Scale, Heating/Vacuum Tables
Versatile range of dispensing applications such as
Solder Paste and SMT Glue, LED Encapsulation,
Silver Epoxy, Dam and Fill, Underill, Cavity Fill,
3D Dispensing via laser height mapping. Standard
cleanroom according to ISO7 (class 10‘000).
Full operator support - Automated error analysis
& KPI. Training, support and troubleshooting via
advanced remote access. Investment protection;
all options and heads retroittable. Modules are
expandable in any direction.
Three processes at the same time. Plug and Play for
valve change. Piezo Jet Valve - super high speed for
low viscosity. Solder Jet Valve, Volume Displace-
ment Valve, Time-Pressure Valve, Archimedean
Screw Valve.
INTEGRATE INTO HIGH SPEED
LINES AND HIGHLY COMPLEX
DISPENSE APPLICATIONS
optional.
tarantula.
Process Max. dispensing speed
(dots/h)
Piezo Jet: > 720‘000 dots/h Time/Pressure: 28‘000 dots/h
Solder Paste Jet: 720‘000 dots/h Archimedean Screw: 24‘000 dots/h
Dispense mode Dot, line, curve, interpolated 3D contour
Accuracy Placement XY dots 40 µm (3σ)
Positioning Z axis 20 µm (3σ)
PCB PCB dimensions 560 x 610 mm (22 x 24“), optional 1’800 x 610 mm (71 x 24“)
Dimensions Machine footprint 1’557 x 1’357 mm (61 x 53“)
Wildlife consistently shows us with breathtaking flexibility how nature can
adapt itself to the many dierent demands of its environment; that is what
inspires us! Essemtec AG is a company with its development and production
site in Switzerland. The product portfolio comprises of production equipment
for electronic assembly and more. Our high-tech solutions can be adjusted
quickly and easily to meet wide ranging requirements; we are therefore able
to respond to all manner of customer requests. That’s why “naturally adaptive”
is our motto across all ranges.
Disclaimer & Copyright:
Information in this brochure is for general information purpose only. Further
details are provided in the specification sheet. All materials contained in this
brochure are copyright © Essemtec AG, Switzerland, January 2024.
Inline with Puma Pick-and-Place
