FUJI EUROPE CORPORATION GmbH
2019/09
Copyright© FUJI CORPORATION. All rights reserved.
Specifications NXTR
Module
1R module
2R module
Panel size
(L x W)
Single conveyor
48 x 48 to 750 x 610 mm
48 x 48 to 370 x 610 mm
Double
conveyor
Single
conveyance
48 x 48 to 750 x 510 mm
48 x 48 to 370 x 510 mm
Dual
conveyance
48 x 48 to 750 x 280 mm
48 x 48 to 370 x 280 mm
Weight
755 kg
865 kg
Base
One module base
Two module base
Air consumption
60 L/min. (ANR)
132 L/min. (ANR)
Machine size (L x W x H)
795 x 1,740 x 1,480 mm
1,590 x 1,740 x 1,480 mm
Weight
540 kg
1,080 kg
Head
RH20
RH08
RH02
Throughput
1
50,000 cph
30,000 cph
9,000 cph
Placing accuracy
1
±0.025 mm Cpk ≥ 1.00
Power
3-phase AC 200 to 230 V ±10V (50/60 Hz)
Air
0.4 MPa
Part supply unit
Cassette-type feeder, Fuji Intelligent Feeder, Tray unit-
RM
*1 Under optimum Fuji conditions
