Fig. B1-1 手前右カバー Front-Right Cover A B DET AIL”A” DET AIL”B” A1 A2 A3 A4 (BASE:Document No.P-310-00X UNIT -1 Fig.B1-1) 1006-001 Fig. B1 高解像度部品認識カメラ HIGH RESOLUTION COMPONENT RECOGNITION CAMERA
CONTENTS
Fig. B1
高解像度部品認識カメラ
HIGH RESOLUTION COMPONENT RECOGNITION CAMERA
Fig. B1-1
手前右カバー
Front-Right Cover
1006-001
Fig. B1
Fig. B1-1
手前右カバー
Front-Right Cover
A
B
DETAIL”A”
DETAIL”B”
A1
A2
A3
A4
(BASE:Document No.P-310-00X
UNIT-1 Fig.B1-1)
1006-001
Fig. B1
高解像度部品認識カメラ
HIGH RESOLUTION COMPONENT RECOGNITION CAMERA
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
A1 0921C802 BRACKET 2 10914051A2-001
A2 221AA030 ROHS_HEX-SCT 4 10914051A2-002
A3 221HA005 WASHER 4 10914051A2-003
A4 221HA303 ROHS_WASHER 4 10914051A2-004
Fig. B1
1006-001
Fig. B1-1
GS-IR110
