Traceability Interfaces 26 SIPLACE Traceability 5.1

Traceability Interfaces

SIPLACE Traceability 5.1 25

2 Traceability Interfaces

Traceability Interfaces

The traceability data generated in the machine are made available for further processing.

The following options for further processing exist:

Traceability data via OIB

The "OIB Interface (Sync)" takes care of the export of traceability data into an advanced processing sub-

system (e.g. MES).

Traceability data in an SQL database

Data in the traceability database can be accessed for viewing via the DBView interface (see Traceability

5.1 User Guide). The traceability SQL database is designed to find the placement data for boards to be

produced. To directly and rapidly locate new traceability data with external subsystems, we recommend

using the event-based OIB interface.

Traceability data as XML files in the file system

The data interface (XML) is primarily available for test purposes and should not be used in productive

operations without deleting or moving the data generated, due to the existing limitations of the file sys-

tem.

Data in the traceability database can be accessed for viewing via the DBView interface (see Traceability

5.1 User Guide). The traceability SQL database is designed to find the placement data for boards to be

produced. To directly and rapidly locate new traceability data with external subsystems, we recommend

using the event-based OIB interface.

NOTICE

Further Information

► For further information about traceability data interfaces, register at http://www.siplace.com

and request the document package.

► If you plan to connect SIPLACE Traceability to your own software interfaces we recom-

mend to contact SIPLACE product management in advance.

Traceability Interfaces

26 SIPLACE Traceability 5.1

Requirements

Software Requirements

SIPLACE Traceability 5.1 27

3 Requirements

Requirements

3.1

3.1 Software Requirements

Software Requirements

To run the Traceability 5.1 system, you must install the following software:

▪ SIPLACE Pro 13.1 (recommended), 13.0 (compatible)

▪ Setup Center 8.1

▪ SIS 13.1 (recommended), 13.0 (compatible)

▪ Trace Service 5.1

▪ Trace Monitor 5.1 (optional) with SIPLACE Studio

▪ Station software:

– 407.05 (SIPLACE 80 F4, F4-6, S20; F5, F5 HM, S23)

– 505.05 SP2 (SIPLACE S25 HM, S27 HM, HS50, HS 50+, HS60, HF, HF3)

– 605.03 SP2 (SIPLACE X2, X3, X4; D1, D2, D3, D4)

– 705.x (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, DX1, DX2, DX4)

– 706.0 (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, SX1 V2, SX2 V2, DX1, DX2, DX4)

– 706.1 (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, X4i S, X4 S, X3 S, SX1 V2, SX2 V2, DX1,

DX2, DX4)

– 707.xx (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, X4 Si, X4 S, X3 S, X2 S, X4 S micron, X4i S

micron, SX1 V2, SX2 V2, DX1, DX2, DX4)

– 708.xx (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, X4 Si, X4 S, X3 S, X2 S, X4 S micron, X4i S

micron, SX1 V2, SX2 V2, DX1, DX2, DX4)

– 709.xx (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, X4 Si, X4 S, X3 S, X2 S, X4 S micron, X4i S

micron, SX1 V2, SX2 V2, DX1, DX2, DX4, TX1, TX2, TX2i, TX micron)
