DEK SMT high performance
understencil cleaning fabrics
DEK SMT high-performance understencil cleaning fabrics provide
effective cleaning and compatibility with multiple print platforms.
Features and benets:
■ Absorbent, vacuum-friendly & fast-wicking
- Special non-woven fabric construction reduces lint, preventing aperture
blockages and contamination
- Fabric does not compromise vacuum power, optimizing aperture cleaning
performance
- Wicks consistently across the full width of the cleaning roll to ensure even
distribution of the cleaning agent for a more productive clean
- Wick time is extremely fast compared to other cleaning fabrics
■ Effective cleaning
- Dry cycle in addition to Wet (Vac/Dry) cycle
- Delivers a superior clean for underside of the stencil
■ Broad machine compatibility
- Suitable for DEK, MPM, Ekra and other on-board cleaning systems, in addition to
advanced understencil cleaners such as DEK Cyclone technology
- 11 meters minimum length reduces number of changeovers and total changeover
time on DEK platforms
- 44 meter length available for latest MPM platform
DEK SMT HIGH PERFORMANCE UNDERSTENCIL CLEANING FABRICS
Part number Platform Fabric width
(mm)
Core width
(mm)
Roll diameter
(mm)
Inner core
(mm)
Roll length (m)
SAP DEK
03127081 176215 All DEK 515 530 56 19 11
03128524 176216 All DEK 400 530 56 19 11
03128532 176217 All DEK 300 530 56 19 11
03128523 173826* All DEK 515 530 56 19 11
03128538 431524 All DEK 607 620 56 19 11
03144917 431424 DEK Cyclone 300 325 56 19 11
*With metalised anti-static packaging.
03217296-01 TQ Platforms 420 448 77 7.5
22
03131502 173451 AP series, UP series,
SPM, MPM125, Accela,
Momentum
320 457 64 19 12
03131501 173450 AP series, UP series,
SPM, MPM125, Accela,
Momentum
443 457 64 19 12
03139825 178911 AP series, UP series,
SPM, MPM125,
Accela, Momentum
597 622 64 19 12
03131512 178864 Accela, Momentum 443 457 100 19 44
03144221 178909 A
ccela, Momentum
546 559 100 19 44
03128533 178908 A
ll Ekra In - Line printers
400 400 53 13 10
03131513 178907 A
ll Ekra In - Line printers
500 500 53 13 10
03131611 431556 A
ll Ekra In - Line printers
500 500 53 13 8
