0203-001 Key N o. P AR T No. P AR T NAME Q’ t y REMA RKS NOTE B-4 33 2 41 1 141 2509 WAS HER SPR 2 2 2 770B- -010- 332 33 3 41 1 141 2608 WAS HER SPR 2 2 2 770B- -010- 333 33 4 41 1 141 2806 WAS HER SPR 3 2 2 770B- -010-…
0203-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
B-4
BF-1005
BF-1605
301 630 114 3798 ASSY,ROTOR 1 770B--010-301
301 630 114 8632 ASSY,ROTOR 1 770D--010-301
301 -01 630 107 2227 SPRING,FLAT 1 1
301 -02 630 114 8571 COVER 1 1
301 -03 630 107 2265 ROTOR 1 1
301 -04 630 113 9166 HOLDER 1
301 -04 630 114 3828 HOLDER 1
301 -05 630 114 8540 HOLDER 1
301 -05 630 114 8670 HOLDER 1
301 -06 630 110 0371 SHAFT 1
301 -06 630 110 0449 SHAFT 1
301 -07 630 110 0395 COVER 1 1
301 -08 630 107 2159 PLATE 1
301 -08 630 108 3254 PLATE 1
301 -09 630 110 0388 PLATE 1
301 -09 630 110 0456 PLATE 1
301 -10 630 114 8588 PLATE 1
301 -10 630 114 8656 PLATE 1
301 -11 630 110 0401 BOLT 1 1
301 -12 630 101 1622 PIN,LOCATE 1 1
301 -16 630 007 1764 BEARING,RADIAL 2 2
301 -17 630 067 1001 MACHINE SCREW 8 8
301 -18 630 113 9029 BOLT,HEX-SCT(WITH WASHERS) 1 1
301 -21 630 008 1053 SET SCREW 1 1
301 -22 630 080 7233 SEAL,RING 1 1
301 -23 411 140 6300 SCR PAN 2X8 1 1
301 -24 411 141 2509 WASHER SPR 2 1 1
301 -25 411 141 3605 WASHER V 2X5X0.3 1 1
301 -26 630 114 4900 PIN,LOCATE 1 1
301 -27 411 141 5500 WASHER F 2X4.3X0.3 2 2
308 630 107 2074 SPRING,COMP 1 1 770B--010-308
309 630 107 2081 SPRING,COMP 1 1 770B--010-309
310 630 107 2142 LEVER 1 1 770B--010-310
315 630 107 2326 BLOCK 1 1 770B--010-315
316 630 107 2333 PLATE 1 1 770B--010-316
317 630 107 2340 PLATE 1 1 770B--010-317
318 630 107 2357 SLIDE 1 1 770B--010-318
319 630 107 2364 SHAFT 1 1 770B--010-319
321 630 107 2388 PIN,GUIDE 1 1 770B--010-321
322 630 107 2395 BOLT 1 1 770B--010-322
323 630 101 1622 PIN,LOCATE 1 1 770D--010-323
327 630 008 1114 BOLT,HEX-SCT 2 2 770B--010-327
328 630 000 7503 BOLT,HEX-SCT 2 2 770B--010-328
329 630 113 9029 BOLT,HEX-SCT(WITH WASHERS) 2 2 770B--010-329
331 411 125 5403 SCR PAN 2X4 2 2 770B--010-331
0203-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
B-4
332 411 141 2509 WASHER SPR 2 2 2 770B--010-332
333 411 141 2608 WASHER SPR 2 2 2 770B--010-333
334 411 141 2806 WASHER SPR 3 2 2 770B--010-334
335 411 141 3902 WASHER V 3X7X0.5 2 2 770B--010-335
BF-1005
BF-1605
MEMO
