Installation Manual, Station Software Version 605.01 SP1 11/2008 Edition
11 of 48
4.1.3 Embedded software
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4 D1 D2 D3 D4
BIOS 02.00 A0300200.bhx
X X X
Application 1 02.13 A0310213.bhx
X X X
Application 2 / X 02.4D A032024D.bhx
X X X
Gantry axes
A 363
Application 2 / Y 02.4D A032024D.bhx
X X X
BIOS 03.3F A040033F.BHX
X X X X X X X
Application 1 03.03 A0410303.bhx
X X X X X X X
Application 2 / X 04.94 A0420494.bhx
X X X X X X X
Gantry axes
A 364
Application 2 / Y 04.94 A0420494.bhx
X X X X X X X
BIOS 02.00 A0300200.bhx
X X X
Application 1 02.13 A0310213.bhx
X X X
Application 2 / star 02.4D A032024D.bhx
X X X
Application 2 / Z 02.4D A032024D.bhx
X X X
C&P head axes
A 363
Application 2 / DP 02.4D A032024D.bhx
X X X
BIOS 03.3F A040033F.BHX
X X X X X X X
Application 1 03.03 A0410303.bhx
X X X X X X X
Application 2 / star 04.94 A0420494.bhx
X X X X X X X
Application 2 / Z 04.94 A0420494.bhx
X X X X X X X
C&P head axes
A 364
Application 2 / DP 04.94 A0420494.bhx
X X X X X X X
BIOS 02.00 A0300200.bhx
X X X
Application 1 02.13 A0310213.bhx
X X X
Application 2 / Z 02.4D A032024D.bhx
X X X
TWIN Head axes
A 363
Application 2 / DP 02.4D A032024D.bhx
X X X
BIOS 03.3F A040033F.BHX
X X X X X
Application 1 03.03 A0410303.bhx
X X X X X
Application 2 / Z 04.94 A0420494.bhx
X X X X X
TWIN Head axes
A 364
Application 2 / DP 04.94 A0420494.bhx
X X X X X
Installation Manual, Station Software Version 605.01 SP1 11/2008 Edition
12 of 48
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4 D1 D2 D3 D4
BIOS 02.00 A0300200.bhx
X X X
Application 1 02.13 A0310213.bhx
X X X
Application 2 / star 02.4D A032024D.bhx
X X X
Axes
C&P20 head
A 363
Application 2 / Z 02.4D A032024D.bhx
X X X
BIOS 03.3F A040033F.BHX
X X X
Application 1 03.03 A0410303.bhx
X X X
Application 2 / star 04.94 A0420494.bhx
X X X
Application 2 / Z 04.94 A0420494.bhx
X X X
BIOS DP 01.04
J0400104.hex
X X X
Axes
C&P20 head
A 364
Application 1 DP
03.06 J0410306.hex
X X X
BIOS 03.3F O040033F.BHX
X
Application 1
01.27
O0410127.bhx
X
WPC 4
feed axis
Application 2
04.5E
O042045E.bhx
X
BIOS 03.3F Q040033F.BHX
X
Application 1
01.27
Q0410127.bhx
X
WPC 4
lifting axis
Application 2
04.5E
Q042045E.bhx
X
BIOS 03.D0 K06003D0.bhx
X X X X
C&P head
(X series)
Application 1
02.10
K0610210.bhx
X X X X
BIOS 03.D0 K07003D0.bhx
X X X
C&P head
(D series)
Application 1
01.19
K0710119.bhx
X X X
BIOS 03.D0 I01003D0.bhx
X X X X
Twin Head
(2nd processor)
Application 1 02.07 I0110207.bhx
X X X X
BIOS 03.D0 I03003D0.bhx
X X X X
Twin Head
(1st processor)
Application 1 02.09 I0310209.bhx
X X X X
BIOS
03.D0 H01003D0.bhx
X X X
C&P20 head
Application 1
01.60 H0110160.bhx
X X X
BIOS
02.01
B0000201.HEX
X
Application 1 05.02 B0010502.hex
X
BIOS
02.01
B0100201.HEX
X
Component table
CAN, 500 KB
Application 1 06.05 B0110605.hex
X
BIOS
01.01
B0200101.hex
X X X X X X
Component table
CAN, 1 MB
Application 1 03.05 B0210305.hex
X X X X X X
BIOS
02.01 B0400201.BHX
X X X
Application 1 04.01 B0410401.bhx
X X X
BIOS
02.00 B0500200.BHX
X X X
Component table
(X table)
Application 1 04.26 B0510426.bhx
X X X
Installation Manual, Station Software Version 605.01 SP1 11/2008 Edition
13 of 48
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4 D1 D2 D3 D4
BIOS
02.01
G0100201.HEX
X
Tape cutter
CAN, 500 KB
Application 1
03.02
G0110302.HEX
X
BIOS
01.00
G0200100.HEX
X X X X X X
Tape cutter
CAN 1 MB
Application 1
01.00
G0210100.HEX
X X X X X X
BIOS
01.01
G0300101.bhx
X X X
Tape cutter
X series
Application 1 01.07 G0310107.bhx
X X X
BIOS
03.06
T0400306.HEX
X X
PCB conveyor
TSP201
Application 1 06.2D T041062D.HEX
X X
BIOS
03.06
T0500306.HEX
X
PCB conveyor
TSP301
Application 1 06.2D T051062D.HEX
X
BIOS
03.06
T0600306.HEX
X X X X
PCB conveyor
X serial/D3
Application 1 06.2D T061062D.HEX
X X X X
BIOS
03.24
E0100324.bhx
X X X X
Application 1 03.85 E0110385.bhx
X X X X
BIOS
03.24
E0200324.bhx
X X X
Main /
subdistributor
Application 1 04.06 E0210406.bhx
X X X
BIOS
03.D0
V05003D0.bhx
X X X X X X X
VISION modules
Application 1
03.03
V0510303.bhx
X X X X X X X
BIOS
02.00
M0200200.BHX
X X X X
MTC 2
Application 1
03.01
M0210301.BHX
X X X X
BIOS
01.00
M0400100.bhx
X X X X
WPC 4
Application 1
01.04
M0410104.BHX
X X X X
BIOS
02.04
L0300204.hex
X X X
Digital pressure
regulation valve
Application 1
03.07
L0310307.hex
X X X
BIOS
01.02
UA100102.HEX
X X X
X feeder
Application 1
01.55
UA110155.HEX
X X X
BIOS
01.01
UB200101.HEX
X X X
X feeder adapter
Application 1 01.07 UB210107.HEX
X X X
BIOS
01.00
UC300100.HEX
X X X
LDU_X modul
Application 1
01.00
UC310100.HEX
X X X
The hardware status of a subsystem is identified by the 3rd digit in the file name.
The example below shows the file name of the BIOS for the main axes of the X-Series:
File name Hardware status
A0
300200.bhx A 363
A0
400309.bhx A 364
