18 5 9 YHP-2(FF,FD) : KGA-M815H-00 MAINTE. PARTS SET No. 1 2 3 4 5 6 7 Qty 2 2 2 2 2 8 4 Part No. 90990-22J001 90990-17J081 90990-17J083 90990-22J014 90990-17J008 KV7-M8171-00 KV7-M81D4-00 Part Name PACKING O-RING O-RING…
185
9
YHP-2(FF,FD) : KGA-M815H-00 MAINTE. PARTS SET
No.
1
2
3
4
5
6
7
Qty
2
2
2
2
2
8
4
Part No.
90990-22J001
90990-17J081
90990-17J083
90990-22J014
90990-17J008
KV7-M8171-00
KV7-M81D4-00
Part Name
PACKING
O-RING
O-RING
PACKING
O-RING
PLATE,SPLING
ROLLER
No.
8
9
10
11
12
13
Qty
12
2
2
8
2
2
NotePart No.
90200-02J015
90200-10J030
K46-M8527-C0
90440-10J008
90440-10J050
$TSR4-M5
Part Name
O-RING
O-RING
FILTER
CIRCLIP
CIRCLIP(E)
JOINT
Note
2
3
NOZZLE 64A ASSY NOZZLE 65A ASSY
5
10
OLD
A
A
4
13
7
6
11
CS1412006J/E-001
YAMAHA MOTOR CO,.LTD.IM Operations
‘2015 Added
‘2015 Added
