SMART-SIZED HIGH
SPEED DISPENSER
Introducing - The Spider - PCB design freedom. State-
of-the-art technology, easily integrated in any line.
l
Up to 2 valves simultaneously
l
5 different valves, large application range
l
Valve up to 720‘000 - System Ø 180‘000 dots/h
l
Up to 2’000’000 dot/h line mode
l
Requires only 1 m² of production loor
l
Machine its through 90 cm wide door
l
No vibration, symmetrical mineral casting
l
No warpage, no thermal drift
l
Mapping of heights using laser technology
l
Compensation of substrate warp / 3D contour
CELL SOLUTION
LINE SOLUTION
Integration in any line
l
Fast, reliable double drive linear motors
l
No maintenance, longest lifetime
dispense technology.
productivity
.
small footprint.
mineral cast.
laser height mapping.
linear motors.
MULTITALENT SOFTWARE AT YOUR FINGERTIPS State of the art, full graphics,
21.5” 16:9 touch screen, Windows - 64 bit, ingertip operation, real time visualiza-
tion zoom at camera windows, all-in-one job planning, universal CAD conversion,
setup optimization, easy deinition of pattern and guided process support
Valves & Pumps
Media Heating
Needle and jet heating system
Level Detection Automatic syringe level detection
Process Control Process control adjustment & stabilization
Integrated Inspection 2D defect detection for dispensed material
Vacuum Cleaning Station, High Precision Scale, Clean Room, Heating/Vacuum Table
Full process control meeting automotive standards and more
Versatile range of dispensing applications such as
Solder Paste and SMT Glue, LED Encapsulation,
Silver Epoxy, Dam and Fill, Underill, Cavity Fill,
2.5D Dispensing via laser height mapping & more
Full operator support - Automated error analysis
& KPI. Training, support and troubleshooting via
advanced remote access. Investment protection;
all options and heads retroittable.
Two processes at the same time. Plug and Play for
valve change. Piezo Jet Valve - super high speed for
low viscosity. Dynamic Shockwave, Volume Displa-
cement, Time/Pressure, Archimedean Screw Valve
INTEGRATE INTO HIGH SPEED
LINES AND HIGHLY COMPLEX
DISPENSE APPLICATIONS
optional.
Process Max. dispensing speed Piezo Jet: > 720‘000 dots/h Time/Pressure: 28‘000 dots/h
Solder Paste Jet: 720‘000 dots/h Archimedean Screw: 24‘000 dots/h
Dispensing mode Dot, line, curve, interpolated 3D contour
Accuracy Placement XY dots 40 µm (3σ)
Positioning Z axis 20 µm (3σ)
PCB PCB dimensions 50 x 50 mm up to 406 x 305 mm (2 x 2” up to 16 x 12”)
Dimensions Machine footprint 880 x 1090 mm (34.7 x 43”)
