General
Family H885
Dimensions
Total length [mm] 21.00
Press ring diameter [mm] 3.20
Outer diameter [mm] 3.05
Collar height [mm] 0.20
Accessories
 
 



 





H885RD
Order code 1003793
Family drawing
All measurements are in mm.

