CTF-36CTrayFeederPartsList.pdf - 第17页
24 21 21 18 30 1 20 23 4 31 9 12 11 25 13 16 14 25 20 15 18 26 26 14 14 25 10 6 25 11 9 7 29 19 17 8 27 5 28 3 26 25 24 3 22 2 25 32 DRIVE 1 No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 …
16
2
17
3
14
5
19
14
10
15
12
11
18
6
1
13
8
11
7
17
17
9
14
17
4
18
GUIDE 2
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
LE6-M5B7S-F0
LE6-M5B7T-F0
LE6-M5B7U-F0
LE6-M5B8P-F0
LE6-M5BD8-00
LE6-M73A1-20
LE6-M5BM0-F0
LE6-M5B8R-F0
LE4-M5BMS-00
LE4-M5BMT-01
LG8-M180S-00
LG8-M180U-01
LG8-M18AA-00
LG8-M18AC-00
LG8-M18AD-00
LG8-M18F1-00
91317-03012
91317-05010
95307-04600
980000. R01
GUIDE,PALETTE L
GUIDE,PALETTE R1
GUIDE,PALETTE R2
STAY,RAIL EV
POST,SPRING
SHIM,RING 0.05
CLAMP ASSY
STAY,RAIL EV
LE4-M5BMS-00
PIN,BRG.
SPACER
SIM
SPRING
WASHER
BEARING
SCREW,TRUSS HEAD
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
NUT, HEXAGON
1
1
1
1
1
1
1
1
1
1
2
1
1
4
1
2
11
8
1
PART NO. PART NAME Q’TY
24
21
21
18
30
1
20
23
4
31
9
12
11
25
13
16
14
25
20
15
18
26
26
14
14
25
10
6
25
11
9
7
29
19
17
8
27
5
28
3
26
25
24
3
22
2
25
32
DRIVE 1
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
LE6-M5B77-00
LE6-M5B7E-F0
LE6-M5B7F-F0
LE6-M5B7K-00
LE6-M5B7M-F0
LE6-M5B80-F0
LE6-M5B71-01
LC0-M71B6-50
LC2-M136R-00
LC7-M71G5-30
LE4-M5B8K-00
LE4-M5B8L-00
LE6-M5B71-10
LE6-M5B72-00
LE6-M5B73-F0
LE6-M5B74-F0
LE6-M5B75-00
LE6-M5B76-00
LE6-M5B7B-F1
LE6-M5BD9-00
LG0-M71FM-20
LE6-M5B8A-F0
LE6-M5BD3-00
91317-03005
91317-03006
91317-03015
91317-04010
91317-08012
92907-03200
92907-08200
92907-10200
90115-10J016
980000. R01
SHAFT 3
GUIDE,HOOK R
STAY,RAIL
COLLAR 2
COVER,DRIVE
HOOK ASSY
CLAMP,BELT 1
BALL BRG.,F.
BOLT
BOLT,HEX.SO.LO HEAD
BOLT
BEARING
CLAMP,BELT 2
NUT 1
SHAFT 1
SHAFT 2
WASHER 1
WASHER 2
ARM
BEARING
WASHER,PLAIN
CLAMP,BELT SENS ASSY
IDLER
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
WASHER, PLAIN
WASHER, PLAIN
WASHER, PLAIN
BOLT,HEX.SOCKET HEAD
1
1
3
1
1
1
1
2
4
1
2
1
2
6
1
2
1
2
1
2
2
1
1
2
11
6
3
1
1
1
1
1
PART NO. PART NAME Q’TY
20
15
14
4
25
17
22
18
6
19
22
2
5
9
10
16
21
11
17
24
3
13
20
15
17
7
8
4
12
1
23
DRIVE 2
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
LC1-M13F2-00
LE4-M5B3E-00
LE6-M5B39-F0
LE6-M5B3C-F0
LE6-M5B3T-00
LE6-M5B78-F0
LE6-M5B79-F0
LE6-M5B7A-F0
LE6-M5B7G-F0
LE6-M5B8G-F0
LE6-M5B8H-F0
LE6-M5BB5-F0
LE6-M5BD2-F0
LE6-M5BD7-00
LG0-M11F1-00
LE6-M65N2-10
91317-05012
91317-05016
91317-05025
91317-06010
91317-06020
92907-05200
98902-04006
92A08-04306
90933-01J002
980000. R01
WASHER,PLAIN
FLANGE
PULLEY,P60
COLLAR,DRIVE
RING,TAPER
BLACKET,MOTOR
HOLDER,DRIVE
SHAFT 4
PULLEY,MOTOR
COLLAR
SUPPORT,ANGLE
KEY
BELT 2
PULLEY,T10F
WASHER,PLAIN
HK MOTOR ASSY
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
BOLT,HEX.SOCKET HEAD
WASHER, PLAIN
SCREW, BINDING HEAD
SCREW, SET
BEARING
1
1
2
1
1
1
1
1
1
1
2
1
1
2
1
10
4
1
2
1
5
4
2
1
PART NO. PART NAME Q’TY
