KMF-1706 13 12 43 19 43 27 14 33 37 20 19 41 43 48 43 45 17 18 50 32 3 28 15 16 50 29 34 32 39 15 1 2 30 41 44 50 40 23 31 39 38 13 47 39 25 42 26 50 46 50 10 11 35 40 4 6 5 35 24 12 39 38 47 21 39 12 39 38 47 12 21 39 3…
KMF-1706
No. Part No. Part Name Q’ty Remarks Rank Level
1 90K41-001250 LABEL WARNING 2 /
Í
2 K93-M1392-00 SPACER 2 /
3 KGF-M5541-00 BARCODE LABEL PS 1 /
4 KGF-M5541-10 BARCODE LABEL PS 1 /
5 KGS-M6701-00 UNIVERSAL BUSH 1 /
Í
6 KGX-M1733-01 CARD GUIDE 2 /
Í
7 KGX-M1737-00 LABEL PALLET POSI. 1 /
8 KJ8-M7451-20 SPRING RACK 1 /
9 KKL-M1774-00 SHAFT 2 /
Í
10 KKL-M1775-00 STOPPER L 1 /
Í
11 KKL-M1776-00 STOPPER R 1 /
Í
12 KKL-M1780-00 PIN LINK 4 /
Í
13 KKL-M1781-00 BUSH 9 /
Í
14 KKL-M1782-00 SHAFT CENTER 1 /
Í
15 KKL-M7462-00 DOOR RUBBER 1 /
16 KLX-M1775-00 BRACKET 1 /
Í
17 KMF-M1766-00 PLATE GUIDE R 1 /
Í
18 KMF-M1767-00 HINGE RACK 2 /
19 KMF-M1777-00 PLATE LINK 2 /
Í
20 KMF-M1778-00 JOINT PLATE 1 /
Í
21 KMF-M177D-00 JOINT KNUCKLE 1 /
Í
22 KMF-M1783-00 COVER 1 /
Í
23 KMF-M653E-00 CYLINDER LATCH ASSY 1 B
Í
24 KMF-M7441-00 PLATE 1 1 /
Í
25 KMF-M7442-00 PLATE 2 1 /
Í
26 KMF-M7443-00 PLATE 3 1 /
Í
27 KMF-M7445-00 PLATE 4 1 /
Í
28 KMF-M7461-00 DOOR 1 /
29 KV4-M177P-00 STOPPER SHAFT 2 /
Í
30 $SC4-M5A SPEED CONTROLLER 2 /
Í
31 90440-01J020 CIRCLIP 9
32 90933-03J683 BEARING 4
33 90990-01J038 BOLT HEX SOCKET HEAD 4
34 91312-03006 BOLT HEX SOCKET HEAD 6
35 91312-04005 BOLT HEX SOCKET HEAD 3
36 91312-04006 BOLT HEX SOCKET HEAD 19
37 91312-05008 BOLT HEX SOCKET HEAD 10
38 92902-04200 WASHER PLAIN 15
No. Part No. Part Name Q’ty Remarks Rank Level
39 92902-05200 WASHER PLAIN 6
40 98902-03006 SCREW BINDING HEAD 18
41 98902-04005 SCREW BINDING HEAD 4
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
3
1
Rack
Rack
KMF-1706
13
12
43
19
43
27
14
33
37
20
19
41
43
48
43
45
17
18
50
32
3
28
15
16
50
29
34
32
39
15
1
2
30
41
44
50
40
23
31
39
38
13
47
39
25
42
26
50
46
50
10
11
35
40
4
6
5
35
24
12
39
38
47
21
39
12
39
38
47
12
21
39
39
38
7
47
36
49
39
8
9
38
51
47
22
39
39
13
12
43
19
43
27
14
33
37
20
19
41
43
48
43
45
17
18
50
32
3
28
15
16
50
29
34
32
39
15
1
2
30
41
44
50
40
23
31
39
38
13
47
39
25
42
26
50
46
50
10
11
35
40
4
6
5
35
24
12
39
38
47
21
39
12
39
38
47
12
21
39
39
38
7
47
36
49
39
8
9
38
51
47
22
39
39
4
1
Guide / Valve
Hook
KMF-1706
No. Part No. Part Name Q’ty Remarks Rank Level
1 $KM-11 MUFFLER 1 /
Í
2 $SL6-01 JOINT 1 /
Í
3 KGS-M6701-00 UNIVERSAL BUSH 1 L=320mm /
Í
4 KGT-M9227-01 BASE CLAMP 1 /
Í
5 KGT-M9228-01 HEAD CLAMP 1 /
Í
6 KGT-M922F-00 SHAFT 2 1 /
Í
7 KGX-M1841-02 BASE PLUNGER 1 /
Í
8 KGX-M1842-00 COVER PLUNGER 1 /
Í
9 KGX-M1843-00 PLUNGER 1 /
Í
10 KGX-M1851-00 BRACKET SPG. 1 /
Í
11 KGX-M1852-00 PLUNGER 1 /
Í
12 KGX-M18A3-02 PLUNGER ASSY. 4 /
Í
13 KGX-M18A4-00 STOPPER ASSY 2 /
Í
14 KK1-M5184-10 SEAL NAME 3 /
Í
15 KKL-M1838-00 BRACKET SENSOR 2 2 /
Í
16 KKL-M1851-00 COVER BELT 1 /
Í
17 KKL-M1861-00 BRACKET SENSOR 1 /
Í
18 KKL-M1862-00 BRACKET SENSOR 1 /
Í
19 KMF-M1801-00 BRACKET 2 /
Í
20 KMF-M1802-00 HOOK AXIS FRAME 1 /
Í
21 KMF-M1809-00 GUIDE PALETTE L1 2 A
Í
22 KMF-M1810-00 GUIDE PALETTE L2 1 A
Í
23 KMF-M1811-00 GUIDE PALETTE R 1 A
Í
24 KMF-M1812-00 GUIDE PALETTE L3 1 A
Í
25 KMF-M1863-00 BRACKET L STOPPER 1 /
Í
26 KMF-M1864-00 BRACKET R STOPPER 1 /
Í
27 KMF-M1868-00 PLATE 1 /
Í
28 KMF-M653F-00 SEN.PLT CHK MGZ ASSY 1 B
Í
29 KMF-M653G-00 SEN.PLT CHK MID ASSY 1 B
Í
30 KMF-M653H-00 SEN.PLT CHK SET ASSY 1 B
Í
31 KMF-M653L-00 ATS VALVE ASSY 1 B
Í
32 KV9-M1839-00 NUT PLATE 2 /
Í
33 $NK-3N NYLON CLIP 7
34 90112-02J010 BOLT HEX SOCKET HEAD 2
35 90440-01J030 CIRCLIP 2
36 90933-02J604 BEARING 1
37 90990-11J003 SCREW PAN HEAD W/W 7
38 90990-41J176 COLLAR 14
No. Part No. Part Name Q’ty Remarks Rank Level
39 91312-03010 BOLT HEX SOCKET HEAD 26
40 91312-03025 BOLT HEX SOCKET HEAD 4
41 91312-04006 BOLT HEX SOCKET HEAD 5
42 91312-04025 BOLT HEX SOCKET HEAD 2
43 91312-06012 BOLT HEX SOCKET HEAD 12
44 91312-08016 BOLT HEX SOCKET HEAD 2
45 91312-08040 BOLT HEX SOCKET HEAD 2
46 91317-03014 BOLT HEX SOCKET HEAD 2
47 92902-03600 WASHER PLAIN 14
48 92902-04200 WASHER PLAIN 2
49 95302-03700 NUT HEXAGON 1
50 98702-03006 SCREW FLAT HEAD 10
51 98902-03008 SCREW BINDING HEAD 2
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
4
1
Guide / Valve
Hook
