12 DEK Neo Horiz in 0 3 iX Machine Fo otprint
11
DEK NeoHorizon 03iX
Machine Productivity Options
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Grid-Lok® tooling
Substrate Transport
Single piece conveyor with flat belts (heavy boards)
Remote board stop (for use with heavy board option)
Dual Speed Motor (for use with standard rails)
Substrate Fixture
All Purpose Clamping (APC) system*
Snuggers (edge clamping)
Foil-less clamps
* Can only be used with Modular rail system
Vision & Verfication
Specification
HawkEye® 750 Paste on Pad Verification
Enabled
HawkEye® 1700 Paste on Pad
Verification
Enabled (camera included)
HawkEye
HawkEye® Bridging (requires HawkEye® 1700
camera)
Data Capture
Specification
Product Data Capture
Verification & Traceability
ProDEK closed loop
Camera Barcode Reader
SMART Factory Integration
Specification
Software & Communications
ASM OIB
IPC CFX
Closed-loop-to-SPI
Connection to ASM Process Expert
ASM Offline Printer Programming
12
DEK NeoHorizin 03iX
Machine Footprint
13
DEK NeoHorizon 03iX
Machine Footprint Back to Back
