RELENTLESS STRONG PICK-AND-PL ACE Str ong, Flexible, A daptive & Modular
RELENTLESS STRONG
PICK-AND-PLACE
Strong, Flexible, Adaptive & Modular
RELENTLESS PLACING
AND JET DISPENSING
Introducing – The Puma Technology – for all types of
components and devices. Expandable in any direction.
l
Highspeed Placement and Jet-Dispensing
l
2 or 4 placement-axes and 1-2 dispense processes
l
Optimum 18’100 cph, up to 54’300 cph inline
l
Valve up to 720‘000 - System Ø 180‘000 dots/h
l
Up to 280 Feeder on 2 m
2
(480 inline - 3 modules)
l
PCB size 560 x 610 mm, optional 1’800 x 610 mm
l
No vibration, symmetrical mineral casting
l
No warpage, no thermal drift
l
Nonstop production, Smart electronic feeder
l
Nonstop feeder and production changeover
CELL SOLUTION
LINE SOLUTION
l
Fast, reliable double drive linear motors
l
No maintenance, longest lifetime
combined process.
productivity
.
small footprint.
mineral cast chassis.
quick changeover.
linear motors.
MULTITALENT SOFTWARE AT YOUR FINGERTIPS State of the art, full graphics,
21.5” 16:9 touch screen, Windows – 64 bit, ingertip operation, real time visualiz-
ation, zoom at camera windows, all-in-one job planning, universal CAD conver-
sion, setup optimization, stock management, ERP/MES connection, data analy-
sis, line management, traceability down to single component and more.
Conigurable heads with 1-4 placement-axis.
2,5D and 3D dispensing and jetting, High resolution
digital Cognex vision system with auto component
teach-in and irregular ball recognition.
Full operator support - Automated error analysis
& KPI. Training, support and troubleshooting via
advanced remote access. Investment protection;
all options and heads retroittable. Machine
expansion in any direction.
Multi lexible feeder, multi lane cassette or highly
accurate single lane feeder. Tape, Stick, Strip,
Palettes and Tray slider. Largest component
spectrum; 008004 (imp.) up to 80 x 80 mm,
component height up to 25 mm.
NEW
Adaptable for different jettable pastes.
Optional integrated inspection. Adaptable for
special applications (nozzle, tappet, tempera-
ture etc.). Optional needles for deep cavities.
solder paste jetting.
A WORLD OF BENEFITS
FROM NPI TO HIGH FLEX,
HIGH SPEED PRODUCTION
Integrated Inspection 2D defect detection for dispensing & pick and place
Laser Height Measurement Compensation of PCB warpage
Dispensing and Jetting Vacuum cleaning station for nozzles and tips
Tray Slider Unique system to increase the amount of trays
Increase Boardsize Table extension to increase the processable board size
Additional: Electrical component test system, vision box to increase component size
to be placed, clean room cover, reel-to-reel, bulk components and more
optional.
