2 1 XY-axis unit XY-axis Section No. Part No. Part Name Q’ty Remarks Rev. Rank Level Replacement Cycle 1 B B B At failur At failure At failure KMN-M653A-00 KMN-M2271-00 KMN-M2671-00 SENSOR BALL SCREW BALL SCREW 6 1 1 X-a…
1
1
Conveyor unit
Conveyor Unit Section
Front
No. Part No. Part Name Q’ty Remarks Rev. Rank Level
Replacement
Cycle
63
5 6
7
7
8
6
3
5
2
E
E
B
B
B
B
B
B
One year
One year
Three years
At failure
At failure
At failure
At failure
At failure
KMN-M9110-00
KMN-M9150-00
KMN-M9260-00
KMN-M653D-00
KMN-M653A-00
KMN-M34X5-00
KMN-M34X6-00
KHN-M9A00-00
BELT,CONV.
PULLEY,CONV.
CLAMP
SENSOR HNS,3104
SENSOR
STEPPING MOTOR
STEPPING MOTOR
SCREW, CONVEYOR
2
8
2
2
5
3
2
1
1
2
3
4
5
6
7
8
5
2
2
2
1
XY-axis unit
XY-axis Section
No. Part No. Part Name Q’ty Remarks Rev. Rank Level
Replacement
Cycle
1
B
B
B
At failur
At failure
At failure
KMN-M653A-00
KMN-M2271-00
KMN-M2671-00
SENSOR
BALL SCREW
BALL SCREW
6
1
1
X-axis
Y-axis
1
2
3
1
1
2
3
1
Top view
3
1
Head unit Z-axis
Z-axis Offset section
3
1
2
B
B
B
At failure
At failure
At failure
KMN-M653B-000
KMN-M653A-000
KMN-M34X5-000
SENSOR HNS,3102
SENSOR
STEPPING MOTOR
2
1
1
No. Part No. Part Name Q’ty Remarks Rev. Rank Level
Replacement
Cycle
1
2
3
