Nozzles And Component Shapes
Nozzle List Operation 3
1
1 Nozzles And Component Shapes
Nozzles And Component Shapes
2-Pin Components and Standard Nozzles
Component description Nozzle Type. Component shape no.
01005R 4005 96
01005C 4005 97
0201R 4006: 302: 306 98
0201C 4006: 302: 306 99
0402R 4001: 4003: 4011: 301: 325 100
0402C 4001: 4003: 4011: 301: 325 101
0402 / F. Bulk Case Feeder 4001: 4003: 4011: 301: 325 1010
0603 4001: 4004: 4011: 4014: 301:
304: 314
102
0603 / F. Bulk Case Feeder 4001: 4004: 4011: 4014: 301:
304: 314
1020
0805 4004: 4014: 304: 314 103
0805 / F. Bulk Case Feeder 4004: 4014: 304: 314 1030
1206 4004: 4014: 4033: 4133: 304:
313: 333
105
1206 / F. Bulk Case Feeder 4004: 4014: 4033: 4133: 304:
313: 333
1050
1210 4004: 4014: 4033: 4133: 304:
313: 333
106
1812 4035: 4235: 335 110
BGA 255 1.50 3820: 518 1100
2010 4035: 4235: 335 111
2220 4035: 4235: 335 112
Ceramic resonator 4034: 4044: 334 1200
TOPLED 4033: 4035: 4133: 4235: 517:
518: 333: 335
1201
BOURNS 3314J potentiometer
(light)
4035: 338 1202
Bridge rectifier 335 1203
MICROMELF 4036: 4046: 336 200
MINIMELF 4032: 4042: 332 201
MAXIMELF 4034: 4044: 334 202
MINIMELF DIODE SOD80 4032: 4042: 332 203
MELF diode (small, thick) SOD87 4032 4034: 4042: 4044: 332 204
MAXIMELF DIODE/LL-41 4034: 4044: 334 205
TANTAL 3.2x1.6 A 4004:4014: 4033: 4133: 304:
313: 314: 333
300
TANTAL 3.4x2.8 B 4033: 4035: 333: 335 301
TANTAL 5.8x3.2 C 4035: 335 302
TANTAL 7.3x4.3 D 516. 337 303
