Nozzles And Component Shapes
8 Nozzle List Operation
PLCC/SOJ Components and Standard Nozzles
Component description Nozzle Type. Component shape no.
QFP 64R 1.0 3817: 3820: 517: 518 903
QFP 80R 1.0 3817: 3820: 517: 518 913
QFP 120 0.8 3817: 3820: 518: 519: 320 916
QFP 128 0.8 3817: 3820: 518: 519: 320 917
QFP 100R 0.65 3817: 3820: 517: 518: 320 922
QFP 160 0.65 518: 519 924
QFP 100B 25mil 3821: 517: 518 933
QFP 132B 25mil 518: 519 934
QFP 164B 25mil 518: 519 935
QFP 196B 25mil 518: 519 936
QFP 208 0.5 518: 519 945
QFP 240 0.5 518: 519 946
QFP 256 0.4 518: 519 953
QFP 100 0.3 517: 320 960
QFP 60Ru 1.0 3821: 517: 518 970
