V ulcan Jet ™ Dispensing Systems Vulcan Jet series dispensing systems provide an advanced, intelligent dispensing solution with piezo-based jetting technology. Jetting discrete dots of adhesive that can be overlapped doe…
Vulcan Jet
™
Dispensing Systems
Vulcan Jet series dispensing systems provide an advanced,
intelligent dispensing solution with piezo-based jetting
technology. Jetting discrete dots of adhesive that can be
overlapped does not require adjustment to the height of the
substrate, allowing for precise dispensing into grooves and
other challenging geometries.
Available in 30 mL size, the applicators feature a modular,
easy-to-clean design with dual heating zones designed to
prolong adhesive life. A separate nozzle heater provides
precise fluid temperature control for optimum dispensing.
When combined with the Unity tabletop automation
system, overall accuracy and functionality of the Vulcan Jet
applicators are enhanced with vision guidance, linear encoded
motion and easy-touch dispensing software to optimize the
process and motion control.
The system’s easy-to-use 7" touchscreen controller interface
offers flow monitoring capabilities, which alert users when
adhesive drops below a pre-determined threshold. The
controller also allows operators to monitor applicator
temperatures and overall system status directly from the
home screen.
Features
n
Non-contact dispensing applies adhesive accurately at
high speeds at a maximum 6 mm distance to the substrate
n
Capable of continuous cycles at 330 Hz for ultra-high
speed dispensing
n
Smaller mass and advanced design allow applicators to
heat up rapidly utilizing a 24V connection
n
Automatic pressure compensation adjusts for changes in
adhesive viscosity, keeping dot dispensing consistent over
time
n
Adhesive level monitoring
n
Temperature standby/set back
n
Cap safety technology provides cap integrity and stability
during times of high internal pressure
n
Accommodates a wide range of hot melt materials,
including polyurethane (PUR)
Benefits
n
Protects operators from incidental touch
n
Highly consistent, accurate dispensing decreases the
amount of rejected products and improves productivity
n
Modular design and robust, long-life parts reduce
equipment maintenance and overall downtime
n
After nozzle change, our one-button stroke adjustment
allows for consistent dispensing
n
Variable interfaces allow for quick connection to parent
machines
n
Discrete I/O
n
Virtual network control
n
Removable cartridges allow for quick changeover and
start-up, maximizing production times
Fast, efcient and clean
adhesive jetting for electronics
assembly
Nordson Corporation
11475 Lakeeld Drive
Duluth, GA 30097-1511
(800) 683-2314
nordson.com/adhesive
Vulcan Jet
™
Dispensing Systems
PAL-17-5840
Issued 9/17
© 2017 Nordson Corporation
All Rights Reserved.
Printed in U.S.A.
Nordson reserves the right to
make design changes between
printings.
Specifications
Weight: 1.85 kg (4 lb)
Cabinet size: 10 in x 7.5 in x 8 in (254 mm x 191 mm x 203 mm)
Maximum fluid pressure: 3.45 bar (50 psi)
Heater output (setpoint range): 7.8° C to 190° C (100° F to 374° F)
Continuous cycle rate: 100Hz to 333Hz
Ambient temperature range: 0° C to 45° C (32° F to 113° F)
Electrical Specifications
Input AC: 100-240 VAC, 1 phase, 50/60 Hz, 2.0 amps
Output AC: 24VDC, 6.25 amps
Internal voltages: 150 VDC, 24 VDC, 3.3 VDC, 1.2 VDC
Nozzle heater wattage: 30 watts
Cartridge heater wattage: 43 watts
Nozzle and cartridge temperature sensing: 120 ohm nickel or RTD
Available Options
n
Pre-warmers
n
Variety of Unity tabletop automation systems
n
Unity HiTemp™ disposable syringe barrels for PUR and other high temperature materials available
from Nordson EFD, call 1-800-556-3484 for more information
For more
information,
speak with your
Nordson
representative
or contact
your Nordson
regional office.
United States
Duluth, Georgia
(800) 683-2314 Phone
(866) 667-3329 Fax
Canada
Markham, Ontario
(800) 463-3200 Phone
(905) 475-8821 Fax
Europe
Erkrath, Germany
(49) 211-9205-0 Phone
(49) 211-254658 Fax
Japan
Tokyo, Japan
(81) 3-5762-2710 Phone
(81) 3-5762-2717 Fax
Asia/Australia/
Latin America
Amherst, Ohio
(440) 985-4797 Phone
(440) 985-1096 Fax
Find us on:
Shown on a
