2
Flexible Arm ø50 mm with Clamp ...................................... 2 units
Ref. FAE070
Fume Extractor ...................................................................... 1 unit
Ref. FAE1-9C (100 V)
Ref. FAE1-1C (120 V)
Ref. FAE1-2C (230 V)
Includes:
- RJ12 Connection Cable ref. 0019751
- USB Connection Cable (USB-A to USB-B) ref. 0021042
- Station Connection Adapter (RJ12 to USB-A) ref. 0023504
Packing List
The following items are included according to purchased reference:
Flexible Hose ø50mm ................................................................ 2 units
Ref. FAE010
Pedal ................................................................................................. 1 unit
Ref. P405
FAE083
Round Metal Nozzle
The cable and the adapter are required to connect Compact
stations with version “E” and previous to FAE1.
This cable is required to connect Modular control units and
Compact stations from version “F” onwards to FAE1.
FRONT
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
Installation
FAE010
Flexible Hose
FAE1
Fume Extractor
FAE070
Flexible Arm with Clamp
FAE1K2
Fume Extractor Kit for 2 Workbenches
Same Assembly Structure
P405
Pedal
RJ12 Connection
Cable
USB Connection Cable
+ Adapter
To Modular control units and Compact
stations from version “F” onwards
To Compact stations with version “E”
and previous ones
Alternative
connections
Workbech
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must be collected and returned to an authorized
recycling facility.
Warranty
Information regarding the warranty of each
product can be found on the final page of its
instruction manual.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
FAE1K2
Fume Extractor Kit for 2 Workbenches
Ref. FAE1-9K2C (100 V)
Ref. FAE1-1K2C (120 V)
Ref. FAE1-2K2C (230 V)
- Net Weight: 16.91 kg / 37.28 lb
- Package Dimensions / Weight: 485 x 725 x 760 mm / 23.2 kg
(L x H x W) 19.09 x 28.54 x 29.92 in / 51.15 lb
Complies with CE standards.
ESD safe.
0034417-041024
