Prepared Kit Portal Modularity, SX1 Page 6 / 6 23.11.2021 Pos. Item no. Description Part marking 9 03073028-02 BG BUFFER STOP 03080913-01 C-PARTS FOR 03064660- 03042541-01 ISO 4762 - M 3 X 6-A2-70 03042552-01 ISO 4762 - …
Prepared Kit Portal Modularity, SX1
Page 4 / 6 23.11.2021
Prepared Kit Portal Modularity, SX1
Page 5 / 6 23.11.2021
Pos. Item no. Description Part marking
00519810-01 PREPARED KIT GANTRY
MODULARITY, SX1
03064660S01 NT SETUP KIT /P001 PREP. 2.G. *
1 03065813-01 SUPPORT GCU CPL.
03052290-03 CABLE SET FOR 2. GANTRY SIPLACE
SX12
*
03068133-03 CABLE: MAIN AXIS VOLTAGE GCU 3
03068134-03 CABLE: AUXILIARY VOLTAGES GCU
3
03068135-02 CABLE: TRAILING INTERFACE 2
03055221-03 CABLE: Y1 MOTOR GANTRY 2
03055223-03 CABLE: Y2 MOTOR GANTRY 2
03055225-02 CABLE: RT-HCU BUS GANTRY 2
03055226-02 CABLE: SENSOR BUS Y MOTOR
GANTRY 2
03055212-01 GROUNDING CABLE 2,5QMM KR M6
KR M5 L=1M
03055213-01 GROUNDINGCABLE 2,5QMM KR M6
KR M5 L=0.5M
00342472-01 PROTECTION HOSE TYPE ZTZ 20
GP-05 B
2 03052200S07 GANTRY-CONTROL-UNIT GCU SPARE PART
3 03050555-01 VISION HOTLINK ADAPTER VHA SPARE PART
4 03064127-03 TRAILING INTERFACE SPARE PART
5 03068747-01 SUPPORT TRAILING-CABLE
INTERFACE CPL.
6 03075584S03 GR Y-TRAILING CABLE VACUUM
CPL.
SPARE PART
00341997-01 LABEL GROUNDING POINT GNYE
D12.5
7 03064172S04 SECONDARY SECTION *
03078323-01 REBUILDING KIT CLAMP CABLE
DRAG CHAIN
03076756-01 CLAMP CABLE DRAG CHAIN
2.PORTAL CPL.
03076662-01 TUBULAR FILM
8 03079647-01 BG BUFFER STOP WITH TRIPPING
DEVICE
00324874-01 PLUG QSC-10H STANDARD PARTS
Prepared Kit Portal Modularity, SX1
Page 6 / 6 23.11.2021
Pos. Item no. Description Part marking
9 03073028-02 BG BUFFER STOP
03080913-01 C-PARTS FOR 03064660-
03042541-01 ISO 4762 - M 3 X 6-A2-70
03042552-01 ISO 4762 - M 4 X 10-A2-70 STANDARD PARTS
00316904-01 DIN 125-A 3,2-140HV-A2
03042542-01 ISO 4762 - M 3 X 8-A2-70 STANDARD PARTS
03008166-01 ISO 4032 - M4-A2-70
03042560-01 ISO 4762 - M 5 X 10-A2-70
00315187-01 DIN 125-A 5,3-140HV-A2
03043120-01 ISO 4762 - M 5 X 14-A2-70
03042560-01 ISO 4762 - M 5 X 10-A2-70
03042531-01 ISO 4762 - M 2,5 X 4-A2-70
03081223-01 PUSH-IN Y-CONNECTOR 12/2X10MM
03075789-01 CONNECTOR QS-10
00324874-01 PLUG QSC-10H STANDARD PARTS
03081445S01 SET MOVE STOP, PREPARED KIT
GANTRY MODU
SPARE PART
