6-B
基
板
コンベアR
Board Conveyor R
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012222AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M49
( KN610012222AA-20-2 )
Ref
No.
Remarks
R
1
Q'ty
6-B
基
板
コンベアR
Board Conveyor R
ｲﾗｽﾄ
No.
Part No.
品　　名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012222AA
Part Name
備　　　考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SENSOR
1
11 N610012890AA
SENSOR
1
16 N610012891AA
STOPPER
1
32 KXFB02N4A03
PLATE
1
33 N210022326AA
PLATE
1
34 N210022327AA
D-PIN
1
36 KXFB02NAA00
BLOCK
2
38 N210021903AA
BRACKET
1
48 N210022330AA
BRACKET
1
49 N210022331AA
BRACKET
2
50 N210022332AA
BRACKET
1
51 KXFB0A4GB00
BRACKET
2
52 N210029095AA
BOLT
1
61 KXF0ASEAA00 CBSS4-6
SPRING
1
62 KXF0CWKAA00 H063-10
CYLINDER
1
63 KXF0DZBAA00 CJPB15-DCG8017G-15(DDA)
SPEED-CONTROLLER
1
64 KXF00YSAA00 AS1211F-M5-04
WASHER
1
65 N510010165AA WASM12-6-1
PIN
1
66 KXF02Y8AA00 MS4-20
PIN
1
67 KXF0303AA00 MSTH6-30
WASHER
1
68 KXF0E0UXA00 FWSSS-D9.0-V6.0-T2.6
JOINT
4
70 N510064398AA M-3ALU-4-X83
JOINT
4
71 N510064400AA M-3AU-4-X83
BOLT
2
72 N986ACB340 ACB3-40
BOLT
4
73 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
8
75 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
2
79 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
8
80 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
2
81 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
4
82 N510017359AA
Hexagon socket head cap screw M4X25-10.9 A2J (Trivalent)
BOLT
2
88 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
WASHER
6
89 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
17
90 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
4
93 N510020098AA Thick washer for M3
WASHER
6
94 N510020099AA Thick washer for M4
WASHER
6
95 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
NUT
6
97 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
NUT
2
98 N510017849AA
Hexagon nut Type-1 Best class M3-6H-4T A2J (Trivalent)
M50
--
( KN610012222AA-20-2 )
6-C
基
板
コンベアR
Board Conveyor R
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012222AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M51
( KN610012222AA-20-3 )
