Introduction – General
7
Introduction– General
The feeders must be regularly checked and then cleaned and/or serviced when necessary. This can significantly reduce
unscheduled feeder downtime. The
S-Feeder Test Station
can be used to check the following:
▪ General functionality
▪ The position of the teeth in the respective toothed wheel (pickup position).
▪ The play of the toothed wheel in the and across the direction of feeding.
If the check finds that tolerance values have been exceeded, we recommend that you pass the feeder concerned on to your
repair department. The
S-Feeder Test Station
is designed for use with the following
SIPLACE
feeders:
Designation Item No.
2 x 8 mm S II 00141096-xx
3 x 8 mm S 00141098-xx
3 x 8 mm SL 00141088- xx
3 x 8 mm S; 0201/0402 00141099- xx
12/16 mm S 00141092- xx
24 / 32 mm S 00141093- xx
44 mm S 00141094- xx
56 mm S 00141095- xx
72 mm S 00141097- xx
88 mm S 00141070- xx
Introduction – Use of Symbols
8
– Use of Symbols
Conventions for the Use of Hazard Symbols
This typeface Marks controls and interface elements in the software.
Marks tasks which are to be performed by the user
NOTICE
Notice
as used in this Operation Manual provides information on the product or indicates a part of the Operation Manual
that requires particular attention.
CAUTION
Attention
as used in this Operation Manual means that slight injury or damage to equipment may occur if the caution instruc-
tions are not followed.
WARNING
Warning
as used in this Operation Manual means that death, severe injury or considerable damage to equipment may occur
if the warning instructions are not followed.
Introduction – Safety Instructions
9
– Safety Instructions
WARNING
Safety notes
The safety instructions in the manual for the relevant feeder take precedence. This instruction manual and the safe-
ty information within are targeted at use of the testing device and the feeder, separately from the machine.
The "external feeder module power supply" is connected to the 230V AC (Europe) / 110V AC (USA); 50/60 Hz line
power supply. When connecting to the 110V supply, you do not need to perform any conversions or switch over
the setting on the power pack.
The "external feeder module power supply" must not be opened or manipulated.! (Danger of electric shock)
Always observe the applicable accident prevention and VDE regulations, plus the specific safety regulations for
handling laboratory equipment and systems outside the machine, as applicable in your country.
The test tapes are made of metal. Do not handle these near live parts.
CAUTION
Checking of feeder
The testing device may only be used to test those feeders approved for its use.
The testing and setting device may only be modified or repaired by the manufacturer.
The setting screws are sealed. If the setting screws are loosened or the seal is damaged, any claims for warranty
will be invalidated and cancelled.
Always transport the testing device in its original packaging.
In order to work safely with the testing and setting device, place it down on a suitably stable and solid table.
