RL131

ERROR CODE LIST

2.3 Error Code Table

DA8EEC-91-030-A0

2.3-3

Error code Message

1870

Update Counter warning

1871

Fan lock warning

1872

External scale warning

1873

Ring communication is not connect

1874

Ring communication time out

1875

Ring communication time out

1876

Communication optical alarm

1877

Controller fan motor life span alarm

1878

Controller fan motor breakdown alarm

1879

AC FAIL detection

1880

Battery low warning

1881

Battery shortage warning

1882

Board temperature overheat error

1883

Keyboard overcurrent alarm

1884

Mouse overcurrent alarm

1885

CPU internal error

1886

CPU battery alarm

1887

CPU thermal alarm

1888

LVDS over current alarm

1889

DVI overcurrent alarm

1890

USB0 overcurrent alarm

1891

USB1 overcurrent alarm

1892

USB2 overcurrent alarm

1893

USB3 overcurrent alarm

1894

USB4 overcurrent alarm

1895

USB5 overcurrent alarm

1896

CF access impossible

1897

Power ON first Safety Stop

1900

Maintenance mode switching error

1901

Maintenance switch abnormal

1920

Feeder install error

2003

PCB carry in restart cancel (right rail belt)

2011

PCB carry in restart cancel (right rail exit)

2012

PCB carry in restart cancel (right rail exit)

2052

PCB carry out restart cancel (left rail belt)

2079

PCB carry out restart cancel (left rail exit)

2209

Rail down condition not satisfies (left rail return limit)

2216

Rail down condition not satisfies (positioner lever return limit)

2221

Rail down condition not satisfies (right rail return limit)

2223

Rail down condition not satisfies (servo switch)

2225

Rail down condition not satisfies (transfer arm return limit)

2231

Rail down condition not satisfies (XY origin)

2232

Rail down condition not satisfies (XY movement)

2258

Arm carry condition not satisfies (left rail traverse limit)

2270

Arm carry condition not satisfies (right rail traverse limit)

2273

Arm carry condition not satisfies (servo switch)

2275

Arm carry condition not satisfies (transfer arm return limit)

2281

Arm carry condition not satisfies (XY origin)

2282

Arm carry condition not satisfies (XY movement)

RL131

ERROR CODE LIST

2.3 Error Code Table

DA8EEC-91-030-A0

2.3-4

Error code Message

2308

Arm slowdown condition not satisfies (left rail traverse limit)

2320

Arm slowdown condition not satisfies (right rail traverse limit)

2323

Arm slowdown condition not satisfies (servo switch)

2331

Arm slowdown condition not satisfies (XY origin)

2332

Arm slowdown condition not satisfies (XY movement)

2358

Rail up condition not satisfies (left rail traverse limit)

2365

Rail up condition not satisfies (positioner lever traverse limit)

2370

Rail up condition not satisfies (right rail traverse limit)

2373

Rail up condition not satisfies (servo switch)

2374

Rail up condition not satisfies (transfer arm traverse limit)

2381

Rail up condition not satisfies (XY origin)

2382

Rail up condition not satisfies (XY movement)

2409

Arm return condition not satisfies (left rail return limit)

2416

Arm return condition not satisfies (positioner return limit)

2421

Arm return condition not satisfies (right rail return limit)

2424

Arm return condition not satisfies (transfer arm traverse limit)

2451

Right rail belt motor timeout

2452

Left rail belt motor timeout

2453

Right rail down movement timeout

2454

Right rail up movement timeout

2455

Left rail down movement timeout

2456

Left rail up movement timeout

2457

Transfer arm forward movement timeout

2458

Transfer arm return movement timeout

2461

Positioner lever forward movement timeout

2462

Positioner lever return movement timeout

2463

Left rail push forward movement timeout

2464

Left rail push return movement timeout

2551

PCB abnormal detection (right rail)

2552

PCB abnormal detection (left rail)

2641

Encoder error

2643

Servo free error

2646

H axis Servo ON error

2647

Handle detection error

2648

No PCB on XY table

2649

Carry miss

2652

Rear left safety detection

2653

Rear right safety detection

2656

Front cover safety detection

2657

Right rail cover safety detection

2658

Left rail cover safety detection

2663

Cancel replacement completion input (open rear left cover)

2664

Cancel replacement completion input (open rear right cover)

2665

Cancel replacement completion input (float left feeder)

2666

Cancel replacement completion input (float right feeder)

2670

Insertion error (Neither lead detection)

2673

Anvil short error (left & right lead detection)

2674

Anvil short error (left lead detection)

2675

Anvil short error (right lead detection)

RL131

ERROR CODE LIST

2.3 Error Code Table

DA8EEC-91-030-A0

2.3-5

Error code Message

2696

No PCB on XY table

2707

H axis origin off

2708

Feeder float detection error

2710

Safety relay reset condition

2712

An error occurred during origin returning for any of C, X, Y, θH, θA or P. Origin return of all axes

canceled.

2713

The θH axis is not at its origin. Origin return of all axes canceled.

2714

The θU axis is not at the waiting position. Origin return of all axes canceled.

2715

An error occurred during origin returning for the θU axis. Origin return of all axes canceled.

2731

PCB carry in restart cancel

2732

PCB carry out restart cancel

2733

PCB sweep out restart cancel

2734

PCB carry start conditional not satisfies

2735

Rail down condition not satisfies

2736

Arm carry condition not satisfies

2737

Arm slowdown condition not satisfies

2738

Rail up condition not satisfies

2739

Arm return condition not satisfies

2748

Emergency stop switch ON safety stop

2756

Axis related error

2757

PCB recognition error (23)

2758

PCB recognition error (16)

2759

PCB recognition error (17)

2760

PCB recognition error (19)

2761

PCB recognition error (45)

2762

PCB recognition error (47)

2763

PCB recognition error (48)

2764

PCB recognition error

2765

PCB recognition error

2766

PCB recognition error

2767

PCB recognition error

2768

Part processing stage cover safety detection

2769

Pulley part cover safety detection

2770

No Pallet part

2771

Pallet part catch error

2772

V cut tape remainder error

2773

V cut return error

2774

Supply unit move error

2777

Feeder move error (Return)

2778

Stockout detect error

4066

This is write protected disk. Please release write protect. Refer to Help for detail.

4067

There is no signature on boot sector. Refer to Help for detail.

9293

Driver soft interlock

9294

Soft task comm. Error

9295

Soft calculation error

9304

Motion incomplete

9305

Soft parameter error

9308

Soft overrun limit

9369

Exclusion process error

9372

Position interrupt error
