70 Technical data Maneuvering radii for the X component trolleys Maneuvering radius R 600 mm Distance L1: Machine center to outer edge of X co mponent trolley 1470 mm Distance L2: Machine center to wall 2070 mm
69
Technical data
Placement machine dimensions
Placement machine center of gravity
X = 0 mm
Y = 0 mm
Z = 630 mm
70
Technical data
Maneuvering radii for the X component trolleys
Maneuvering radius R 600 mm
Distance L1: Machine center to outer edge of X component
trolley
1470 mm
Distance L2: Machine center to wall 2070 mm
71
Technical data
Maneuvering radii for MTC
Maneuvering radius R 750 mm
Distance L1: Machine center to outer edge of MTC 1938 mm
Distance L2: Machine center to wall 2688 mm
