Ref No. Remark s R 1 Q'ty 4-E 基 板 位置 決 めリフト (L) Board Positioning Lif t(L) ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット品 番 Kit Name キット名称 N610012845AA Part Nam e 備 考 ｾｸｼｮﾝNo. PARTS LIST Section No. R 3 JOINT…
4-E
基
板
位置
決
めリフト (L)
Board Positioning Lift(L)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012845AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M35
( KN610012845AA-22-5 )
Ref
No.
Remarks
R
1
Q'ty
4-E
基
板
位置
決
めリフト (L)
Board Positioning Lift(L)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012845AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
JOINT
2
22 N210039711AA
PLATE
2
23 N210093063AA
PLATE
1
27 N210025917AA
DOG
1
50 N210026250AD
AIR-SLIDE
1
87 KXF0DLFAA00 MXPJ6-5-X23
JOINT
2
88 N510064400AA M-3AU-4-X83
BOLT
2
96 N510017747AA
Hexagon head bolt Best class M5X25-6g 4T A2J (Trivalent)
BOLT
2
100 N510017744AA
Hexagon head bolt Best class M5X16-6g 4T A2J (Trivalent)
CYLINDER
2
106 KXF016EAA00 BDA10X5
LINEAR-WAY
2
107 N510016310AA LWLF24C1R54BCSE723
JOINT
4
108 KXF02T7AA00 M-5H-4
SCREW
4
130 N510018378AA
Hexagon socket set screw Cup point M5X20-45H A2J (Trivalent)
BOLT
4
133 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
4
136 N510017313AA
Hexagon socket head cap screw M3X16-10.9 A2J (Trivalent)
BOLT
2
137 N510017376AA
Hexagon socket head cap screw M4X6-10.9 A2J(Trivalent)
BOLT
2
138 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
4
139 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
4
146 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
2
150 N510017433AA
Hexagon socket head cap screw M6X16-10.9 A2J (Trivalent)
WASHER
2
155 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
2
157 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
WASHER
4
160 N510020098AA Thick washer for M3
NUT
8
169 N510017862AA
Hexagon nut Type-1 Best class M5-6H-4T A2J (Trivalent)
COVER
1
185 N210069903AA
BRACKET
1
186 N210069902AB
CABLE-BEAR
1
187 N510035684AA CDP015 W25 R37-405L.C(DOWN/DOWN)
BOLT
4
188 N510017627AA
Hexagon socket Flat head bolt M4X6-10.9 A2J (Trivalent)
M36
--
( KN610012845AA-22-5 )
4-F
基
板
位置
決
めリフト (L)
Board Positioning Lift(L)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012845AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M37
( KN610012845AA-22-6 )
