MODEL GXH-1
0409-002
68
ヘッド部
HEAD SECTION
Fig. M-2
ノズル上下部
Nozzle Leveller
103
145
135
118
143
154
166
161
151
166
161
151
125
127
157
.
162
.
168
153
.
161
.
167
155
.
162
.
168
156
.
162
.
168
156
.
162
.
168
155
.
162
.
168
139
133
152
1
15
See Fig.M-4
Key No.321
MODEL GXH-1
1012-003
69
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
M-2
4Unit/1Machine
103 6301778198 MOTOR,AC-SERVO 1 -M33 803M--210-003 4M150293
115 6301264783 BLOCK(BLOCK) 1 803M--210-115 211G3486
118
6301273426 BRACKET 1 803M--210-118 211F8434
125
6301250311 CAM FOLLOWER 1 803M--210-015 222H0133
127 6301273433 GUIDE,LINEAR(KR-UNIT) 1
803M--210-017 222L0703
133 6301250878 SENSOR,PHOT
O 3 -B3102,-B3104,-B3105
803M--210-033
23G10087
135 6301271682 BRACKET
1 803M--210-135 211F8403
139 6301272740
BRACKET 1 803M--210-139 211F8424
143 6301274621
BRACKET 1 803M--210-143 211F8450
145 6301250588
COUPLING 1 803M--210-025 223C0203
151 6300123791 BOL
T,HEX-SCT 4 M2.5X5 221A0150
152 6300007473 BOL
T,HEX-SCT 3 M2.5X8 221A0002
153 6300138924 BOL
T,HEX-SCT 2 M2.5X10 221A0154
154 6300007480 BOL
T,HEX-SCT 2 M2.5X12 221A0003
155 6300007503 BOL
T,HEX-SCT 5 M3X6 221A0005
156 6300007527 BOL
T,HEX-SCT 4 M3X10 221A0007
157 411
1409905 NUT HEX 3 1 M3 221F0079
161 411
1416606 WASHER SPR 2.5 6 SW2.5 221H0279
162 411
1412806 WASHER SPR 3 10 SW3 221H0281
166 411
1415708 WASHER F 2.5X5X0.5 4 FWS2.5 221H0336
167 411
1413803 WASHER V 2.5X6.5X0.5 2 FW2.5 221H0310
168 411
1413902 WASHER V 3X7X0.5 10 FW3 221H0312
MODEL GXH-1
0409-002
70
ヘッド部
HEAD SECTION
Fig. M-3
ノズル選択部
Nozzle Selecter
231
226
See Fig.M-4
Key No.310
253
202
221
257
222
217
211
241
251
232
220
247
252
253
254
261
256
255
244
258
.
262
.
263
