A 24 はんだ供給ユニット ( オプション ) Solder supply unit (option) 48 51 67 12 12 67 52 53 14 23 14 54 58 68 2 3 68 58 55 57 57 49 50 26 62 13 22 28 29 30 33 34 66 70 73 71 72 74 69 15 15 1 1 21 21 60 61 56 16 31 18 32 19 1 35 35 4 36…
A23
M
サイズ部品
(
オプション
)
M size parts (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZ3-282-481-31
ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ
(CBSA3-6)
BOLT (CBSA3-6)
4
2 EZ4-455-358-03
ﾌﾞﾚ-ﾄﾞ ﾎﾙﾀﾞ
HOLDER, BLADE
1
3 EZ4-455-359-02
ﾌﾞﾚ-ﾄﾞ ｽﾍﾟ-ｻ
SPACER, BLADE
2
4 EZ4-455-360-02
ｸﾘ-ﾆﾝｸﾞ ﾊﾞ-
M
BAR (M), CLEANING
1
5 EZ4-455-363-02
ｸﾘ-ﾆﾝｸﾞ ﾌﾞﾚ-ﾄﾞ
M
BLADE (M), CLEANING
2
6 EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
8
7 EZ7-683-418-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X6
BOLT,HEXAGON SOCKET 4X6
4
A-83
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
48
51
67
12
12
67
52
53
14
23
14
54
58
68
2
3
68
58
55
57
57
49
50
26
62
13
22
28
29
30
33
34
66
70
73
71
72
74
69
15
15
11
21
21
60
61
56
16
31
18
32
19
1
35
35
4
36
9
9
38
39
40
41
42
43
44
25
64
45
46
37
47
17
59
10
63
65
10
12
24
12
6
5
7
8
27
20
A-84
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZA-1899-202-A
SC MOUNT
SC MOUNT
2
2 EZ1-492-030-13
ｾﾝｻ-
ASSY (IN1-12)
SENSOR ASSY (IN1-12)
1
3 EZ1-492-030-23
ｾﾝｻ-
ASSY (IN1-13)
SENSOR ASSY (IN1-13)
1
4 EZ1-492-032-92
ｾﾝｻ-
ASSY (IN1-15)
SENSOR ASSY (IN1-15)
1
5 EZ1-492-038-12
ｾﾝｻ-
ｱﾝﾌﾟ
ASSY (IN1-16)
AMMPLIFIER ASSY(IN1-16),SENSOR
1
6 EZ1-492-041-72
ｾﾝｻ-
ASSY (S12ORG)
SENSOR ASSY (S12ORG)
1
7 EZ1-492-044-52
ｾﾝｻ-
ASSY (S12CW)
SENSOR ASSY (S12CW)
1
8 EZ1-492-044-62
ｾﾝｻ-
ASSY (S12CCW)
SENSOR ASSY (S12CCW)
1
9 EZ1-492-266-11
ｾﾝｻ- ﾍﾂﾄﾞ
ASSY (IN1-16)
HEAD ASSY, SENSOR (IN1-16)
2
10 EZ1-492-361-12
ｾﾝｻ-
ASSY (IN1-14)
SENSOR ASSY (IN1-14)
1
11 EZ1-855-287-11
ｻ-ﾎﾞ ﾓ-ﾀ-
(C13)
MOTOR, SERVO (SGMJV-
01ADAHC01)
1
12 EZ2-022-663-21
ﾍｲｺｳﾋﾟﾝ
(
ﾌｱｲ
5M6X10)
PIN, PARALLEL (DIA. 5M6X10)
4
13 EZ2-022-680-21
C
ｶﾞﾀ ﾄﾒﾜ
(STWS16)
RING, C TYPE RETAINING(STWS16)
1
14 EZ2-022-747-01
ﾌﾛ-ﾃｲﾝｸﾞ ｼﾞﾖｲﾝﾄ
(FJT5-0.8-3)
JOINT, FLOATING (FJT5-0.8-3)
1
15 EZ2-023-037-01
ｽﾘﾂﾄ
(E39-S64)
SLIT (E39-S64)
2
16 EZ2-592-891-01
C
ｶﾞﾀ ﾄﾒﾜ
(STWS10)
RING (STWS10),C TYPE RETAINING
1
17 EZ2-674-572-21
ﾊﾞ-ﾌﾞ ﾂｷﾞﾃ
(M-5ALN-4)
JOINT (M-5ALN-4), BAMBOO
2
18 EZ2-680-401-31
ﾍｲｺｳ ｷ-
(KED3-8)
KEY, PARALLEL (KED3-8)
1
19 EZ2-990-379-01
ｼﾁﾕｳ
SUPPORT
8
20 EZ3-217-532-11
ｱﾂｼﾕｸ ﾊﾞﾈ
(UL4-20)
SPRING, COMPRESSION (UL4-20)
1
21 EZ3-854-267-01
ﾎﾞ-ﾙﾍﾞｱﾘﾝｸﾞ
(6800ZZ)
FLANGELESS BALL BEARING
2
22 EZ4-165-030-01
ﾅﾂﾄ
(TNBC-ATM12-R)
NUT (TNBC-ATM12-R)
1
23 EZ4-184-270-61
ｹ-ﾌﾞﾙ ﾍﾞｱ
(TKP0180W40R28-13L*)
BARE (TKP0180W40R28-13L+PIA*)
1
24 EZ4-184-296-31
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
6M6X10 SUS)
PIN (DIA. 6M6X10 SUS),PARALLEL
2
25 EZ4-184-366-11
ｼﾘﾝﾀﾞ
-
(CDJ2B16-222A-B)
CYLINDER (CDJ2B16-222A-B)
1
26 EZ4-184-367-01
ﾘﾆｱ ｳｴｲ
(MES15C2R400)
RAIL (MES15C2R400),LINEAR
1
27 EZ4-284-642-01
ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ
(AS1002F-04)
CONTROLLER (AS1002F-04), SPEED
2
28 EZ4-455-419-02
ﾎﾟﾂﾄ ﾎﾙﾀﾞ-
HOLDER, POT
1
29 EZ4-455-420-01
ﾄﾞｸﾞ
DOG
1
A-85
