A24 はんだ供給ユニ ット ( オプシ ョン ) Solder supply unit (option) ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 30 EZ4- 455 - 421 - 01 ﾎﾟﾂﾄ ｵｻｴ ﾈｼﾞ SCRE W, POT RET AINER 1 31 EZ4- 455 - …
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZA-1899-202-A
SC MOUNT
SC MOUNT
2
2 EZ1-492-030-13
ｾﾝｻ-
ASSY (IN1-12)
SENSOR ASSY (IN1-12)
1
3 EZ1-492-030-23
ｾﾝｻ-
ASSY (IN1-13)
SENSOR ASSY (IN1-13)
1
4 EZ1-492-032-92
ｾﾝｻ-
ASSY (IN1-15)
SENSOR ASSY (IN1-15)
1
5 EZ1-492-038-12
ｾﾝｻ-
ｱﾝﾌﾟ
ASSY (IN1-16)
AMMPLIFIER ASSY(IN1-16),SENSOR
1
6 EZ1-492-041-72
ｾﾝｻ-
ASSY (S12ORG)
SENSOR ASSY (S12ORG)
1
7 EZ1-492-044-52
ｾﾝｻ-
ASSY (S12CW)
SENSOR ASSY (S12CW)
1
8 EZ1-492-044-62
ｾﾝｻ-
ASSY (S12CCW)
SENSOR ASSY (S12CCW)
1
9 EZ1-492-266-11
ｾﾝｻ- ﾍﾂﾄﾞ
ASSY (IN1-16)
HEAD ASSY, SENSOR (IN1-16)
2
10 EZ1-492-361-12
ｾﾝｻ-
ASSY (IN1-14)
SENSOR ASSY (IN1-14)
1
11 EZ1-855-287-11
ｻ-ﾎﾞ ﾓ-ﾀ-
(C13)
MOTOR, SERVO (SGMJV-
01ADAHC01)
1
12 EZ2-022-663-21
ﾍｲｺｳﾋﾟﾝ
(
ﾌｱｲ
5M6X10)
PIN, PARALLEL (DIA. 5M6X10)
4
13 EZ2-022-680-21
C
ｶﾞﾀ ﾄﾒﾜ
(STWS16)
RING, C TYPE RETAINING(STWS16)
1
14 EZ2-022-747-01
ﾌﾛ-ﾃｲﾝｸﾞ ｼﾞﾖｲﾝﾄ
(FJT5-0.8-3)
JOINT, FLOATING (FJT5-0.8-3)
1
15 EZ2-023-037-01
ｽﾘﾂﾄ
(E39-S64)
SLIT (E39-S64)
2
16 EZ2-592-891-01
C
ｶﾞﾀ ﾄﾒﾜ
(STWS10)
RING (STWS10),C TYPE RETAINING
1
17 EZ2-674-572-21
ﾊﾞ-ﾌﾞ ﾂｷﾞﾃ
(M-5ALN-4)
JOINT (M-5ALN-4), BAMBOO
2
18 EZ2-680-401-31
ﾍｲｺｳ ｷ-
(KED3-8)
KEY, PARALLEL (KED3-8)
1
19 EZ2-990-379-01
ｼﾁﾕｳ
SUPPORT
8
20 EZ3-217-532-11
ｱﾂｼﾕｸ ﾊﾞﾈ
(UL4-20)
SPRING, COMPRESSION (UL4-20)
1
21 EZ3-854-267-01
ﾎﾞ-ﾙﾍﾞｱﾘﾝｸﾞ
(6800ZZ)
FLANGELESS BALL BEARING
2
22 EZ4-165-030-01
ﾅﾂﾄ
(TNBC-ATM12-R)
NUT (TNBC-ATM12-R)
1
23 EZ4-184-270-61
ｹ-ﾌﾞﾙ ﾍﾞｱ
(TKP0180W40R28-13L*)
BARE (TKP0180W40R28-13L+PIA*)
1
24 EZ4-184-296-31
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
6M6X10 SUS)
PIN (DIA. 6M6X10 SUS),PARALLEL
2
25 EZ4-184-366-11
ｼﾘﾝﾀﾞ
-
(CDJ2B16-222A-B)
CYLINDER (CDJ2B16-222A-B)
1
26 EZ4-184-367-01
ﾘﾆｱ ｳｴｲ
(MES15C2R400)
RAIL (MES15C2R400),LINEAR
1
27 EZ4-284-642-01
ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ
(AS1002F-04)
CONTROLLER (AS1002F-04), SPEED
2
28 EZ4-455-419-02
ﾎﾟﾂﾄ ﾎﾙﾀﾞ-
HOLDER, POT
1
29 EZ4-455-420-01
ﾄﾞｸﾞ
DOG
1
A-85
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
30 EZ4-455-421-01
ﾎﾟﾂﾄ ｵｻｴ ﾈｼﾞ
SCREW, POT RETAINER
1
31 EZ4-455-422-02
ｼﾘﾝﾀﾞ ﾛﾂｸ
LOCK, CYLINDER
1
32 EZ4-455-423-03
ﾍﾞ-ｽ ﾌﾞﾛﾂｸ
BLOCK, BASE
1
33 EZ4-455-424-01
ﾎﾟﾂﾄ ｵｻｴ ﾌﾟﾚ-ﾄ
PLATE, POT RETAINER
1
34 EZ4-455-425-01
ｽﾗｽﾄ ﾘﾝｸﾞ
RING, THRUST
1
35 EZ4-455-426-01
ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ
BLOCK, CLAMP
2
36 EZ4-455-427-02
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR
1
37 EZ4-455-428-02
ﾀﾞｲｹｲ ﾈｼﾞ
SCREW, TRAPEZOIDAL
1
38 EZ4-455-429-01
ｶﾗ-
1
COLLAR (1)
1
39 EZ4-455-430-01
ｼﾔﾌﾄ ﾌﾟﾚ-ﾄ
PLATE, SHAFT
1
40 EZ4-455-431-02
ｸﾗﾝﾌﾟ ｶﾊﾞ-
COVER, CLAMP
1
41 EZ4-455-432-01
ｷﾞﾔ ｶﾊﾞ-
COVER, GEAR
1
42 EZ4-455-433-01
ｷﾞﾔ
(1)
GEAR (1)
1
43 EZ4-455-434-01
ｷﾞﾔ ｼﾔﾌﾄ
SHAFT, GEAR
1
44 EZ4-455-435-02
ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ
BRACKET, MOTOR
1
45 EZ4-455-436-01
ｶﾗ-
2
COLLAR (2)
1
46 EZ4-455-437-01
ｶﾗ-
3
COLLAR (3)
1
47 EZ4-455-438-03
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR
1
48 EZ4-455-439-02
ﾍﾞ-ｽ ﾌﾟﾚ-ﾄ
PLATE, BASE
1
49 EZ4-455-440-01
ｼﾞﾖｲﾝﾄ ﾌﾞﾛﾂｸ
BLOCK, JOINT
1
50 EZ4-455-441-01
ｽﾗｲﾄﾞ ﾍﾞ-ｽ
BASE, SLIDE
1
51 EZ4-455-442-01
ｼﾘﾝﾀﾞ ﾌﾞﾗｹﾂﾄ
BRACKET, CYLINDER
1
52 EZ4-455-443-01
ｼﾘﾝﾀﾞ ｼﾞﾖｲﾝﾄ
JOINT, CYLINDER
1
53 EZ4-455-444-01
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ
BRACKET, CABLE BARE
1
54 EZ4-455-446-01
ｾﾝｻ ｱﾝﾌﾟ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR AMPLIFIER
1
55 EZ4-455-447-01
ﾘｱ ｶﾊﾞ-
COVER, REAR
1
56 EZ4-456-910-51
ｻﾎﾟ-ﾄ ﾕﾆﾂﾄ
(BUM-8)
SUPPORT UNIT (BUM-8)
1
57 EZ4-456-950-01
ｳﾚﾀﾝ ﾔｷﾂｹ ｸﾂｼﾖﾝ
(UHBKS12-10-M4)
CUSHION (UHBKS12-10-M4)
2
58 EZ4-457-146-01
ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ-
(AS1201F-M5-04A)
CONTROLLER (AS1201F-M5-04A)
2
59 EZ4-457-148-02
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
2
BRACKET (2), SENSOR
1
A-86
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
60 EZ4-457-152-01
ｷﾞｱ
(GEFHBS1.5-26-10-15-W0-WD*)
GEAR(GEFHBS1.5-26-10-15-W0-W*)
1
61 EZ4-457-152-11
ｷﾞｱ
(GEFKBS1.5-20-10-8N-W0)
GEAR (GEFKBS1.5-20-10-8N-W0)
1
62 EZ4-457-156-01
ﾍｲｺｳ ｷ-
(KEG5-20)
KEY (KEG5-20), PARALLEL
1
63 EZ4-457-168-01
ｶｲﾍｲ ｴｱ ﾁﾔﾂｸ
(MHY2-16D)
AIR ZIPPER (MHY2-16D)
1
64 EZ4-457-170-01
ﾘﾆｱ ｳｴｲ
(MXD20C1R175H/E30)
RAIL (MXD20C1R175H/E30),LINEAR
1
65 EZ4-457-173-01
ｺﾞｸｳｽ ｼﾞﾕｼ ﾜﾂｼﾔ
(SWSPT15-6-0.5)
WASHER (SWSPT15-6-0.5), RESIN
1
66 EZ4-457-176-01
ｸﾂｼﾖﾝ ｺﾞﾑ
(WRBNA60-25-5)
RUBBER (WRBNA60-25-5),
CUSHION
1
67 EZ4-466-341-01
ﾄﾘﾂｹ ﾊﾞﾝﾄﾞ ｾﾂﾄ
(BJ2-016)
BAND SET (BJ2-016), FITTING
2
68 EZ4-466-342-01
ｵ-ﾄ ｽｲﾂﾁ ﾎﾙﾀﾞ ｾﾂﾄ
(BJ3-1)
HOLDER SET (BJ3-1),AUTO SWITCH
2
69
EZ4-455-448-01
ﾎﾟﾂﾄ ﾘﾝｸﾞ (SE) 千住金属工業用
RING (SE), POT For Senjyu.JAPAN
1
左記タイプ以外、またはどのタ
イプかが不明な場合は代理店
または弊社にお問い合わせく
ださい。
If the part type is other than
those on the left or unknown,
please contact the dealer.
EZ4-455-448-11
ﾎﾟﾂﾄ ﾘﾝｸﾞ (TA) タムラ製作所用
RING (TA), POT For TAMURA.JAPAN
1
EZ4-455-448-21
ﾎﾟﾂﾄ ﾘﾝｸﾞ
(NI)
その他 日本製
RING (NI), POT For Other.JAPAN
1
70 EZ4-455-416-01
ｼﾘﾝﾀﾞ
CYLINDER
1
71 EZ4-455-417-01
ﾊﾟﾂｷﾝ ﾌﾟﾚ-ﾄ
PLATE, PACKING
1
72 EZ4-455-418-01
ﾅﾂﾄ
NUT
1
73
EZ4-183-335-01
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
58)
PACKING (DIA. 58)
1
左記タイプ以外、またはどのタ
イプかが不明な場合は代理店
または弊社にお問い合わせく
ださい。
If the part type is other than
those on the left or unknown,
please contact the dealer.
EZ4-183-335-11
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
57.5)
GASKET (DIA. 57.5)
1
EZ4-183-335-21
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
57)
GASKET (DIA. 57)
1
EZ4-183-335-31
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
56.5)
GASKET (DIA. 56.5)
1
EZ4-183-335-41
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
56)
GASKET (DIA. 56)
1
74 EZ4-183-228-01
ﾁﾕ-ﾌﾞ
TUBE
1
EZ4-701-529-01
ﾀｲﾏｳﾝﾄ
(MB1)
TIE MOUNT (MB1)
2
EZ4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
1
EZ2-022-865-01
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
3M6X10)
PIN, PARALLEL (DIA. 3M6X10)
1
EZ4-457-150-01
ﾀﾞﾝﾂｷ ﾎﾞﾙﾄ
(DBS4-5-6)
BOLT (DBS4-5-6), STEP
1
EZ7-627-452-38
ｾｲﾐﾂﾈｼﾞ
+K 2X5, TYPE 1
SCREW,PRECISION +K 2X5
4
EZ4-701-528-11
ﾄﾗｽ ｺﾈｼﾞ
(M4X6)
SCREW (M4X6)
7
EZ7-682-160-01
+P 4X6
SCREW +P 4X6
3
A-87
