4-14 4 ■7.FrontLeft(OUT) 地址 位数 名称 0008h 0 SSIDOBit0 0008h 1 SSIDOBit1 0008h 2 SSIDOBit2 ■8.FrontLeft(IN) 地址 位数 名称 0000h 0 Device No. Bit0 0000h 1 Device No. Bit1 0000h 2 Device No. Bit2 0000h 3 Device No. B…
4-13
4
<S10_4. Hi11 (IN)>
地址 位数 名称
0027h 6 Air Pressure: Head A8 Bit 14
0027h 7 Air Pressure: Head A8 Bit 15
0028h 0 Air Pressure: Head A9 / Air Pressure: Head A9 Bit 0
0028h 1 Air Pressure: Head A9 Bit 1
0028h 2 Air Pressure: Head A9 Bit 2
0028h 3 Air Pressure: Head A9 Bit 3
0028h 4 Air Pressure: Head A9 Bit 4
0028h 5 Air Pressure: Head A9 Bit 5
0028h 6 Air Pressure: Head A9 Bit 6
0028h 7 Air Pressure: Head A9 Bit 7
0029h 0 Air Pressure: Head A9 Bit 8
0029h 1 Air Pressure: Head A9 Bit 9
0029h 2 Air Pressure: Head A9 Bit 10
0029h 3 Air Pressure: Head A9 Bit 11
0029h 4 Air Pressure: Head A9 Bit 12
0029h 5 Air Pressure: Head A9 Bit 13
0029h 6 Air Pressure: Head A9 Bit 14
0029h 7 Air Pressure: Head A9 Bit 15
002Ah 0
Air Pressure: Head A10 / Air Pressure: Head A10 Bit 0
002Ah 1 Air Pressure: Head A10 Bit 1
002Ah 2 Air Pressure: Head A10 Bit 2
002Ah 3 Air Pressure: Head A10 Bit 3
002Ah 4 Air Pressure: Head A10 Bit 4
002Ah 5 Air Pressure: Head A10 Bit 5
002Ah 6 Air Pressure: Head A10 Bit 6
002Ah 7 Air Pressure: Head A10 Bit 7
002Bh 0 Air Pressure: Head A10 Bit 8
002Bh 1 Air Pressure: Head A10 Bit 9
002Bh 2 Air Pressure: Head A10 Bit 10
002Bh 3 Air Pressure: Head A10 Bit 11
002Bh 4 Air Pressure: Head A10 Bit 12
002Bh 5 Air Pressure: Head A10 Bit 13
002Bh 6 Air Pressure: Head A10 Bit 14
002Bh 7 Air Pressure: Head A10 Bit 15
002Ch 0
Air Pressure: Head A11 / Air Pressure: Head A11 Bit 0
002Ch 1 Air Pressure: Head A11 Bit 1
002Ch 2 Air Pressure: Head A11 Bit 2
002Ch 3 Air Pressure: Head A11 Bit 3
002Ch 4 Air Pressure: Head A11 Bit 4
002Ch 5 Air Pressure: Head A11 Bit 5
002Ch 6 Air Pressure: Head A11 Bit 6
002Ch 7 Air Pressure: Head A11 Bit 7
002Dh 0 Air Pressure: Head A11 Bit 8
002Dh 1 Air Pressure: Head A11 Bit 9
002Dh 2 Air Pressure: Head A11 Bit 10
002Dh 3 Air Pressure: Head A11 Bit 11
002Dh 4 Air Pressure: Head A11 Bit 12
002Dh 5 Air Pressure: Head A11 Bit 13
002Dh 6 Air Pressure: Head A11 Bit 14
地址 位数 名称
002Dh 7 Air Pressure: Head A11 Bit 15
002Eh 0
Air Pressure: Head A12 / Air Pressure: Head A12 Bit 0
002Eh 1 Air Pressure: Head A12 Bit 1
002Eh 2 Air Pressure: Head A12 Bit 2
002Eh 3 Air Pressure: Head A12 Bit 3
002Eh 4 Air Pressure: Head A12 Bit 4
002Eh 5 Air Pressure: Head A12 Bit 5
002Eh 6 Air Pressure: Head A12 Bit 6
002Eh 7 Air Pressure: Head A12 Bit 7
002Fh 0 Air Pressure: Head A12 Bit 8
002Fh 1 Air Pressure: Head A12 Bit 9
002Fh 2 Air Pressure: Head A12 Bit 10
002Fh 3 Air Pressure: Head A12 Bit 11
002Fh 4 Air Pressure: Head A12 Bit 12
002Fh 5 Air Pressure: Head A12 Bit 13
002Fh 6 Air Pressure: Head A12 Bit 14
002Fh 7 Air Pressure: Head A12 Bit 15
4-14
4
■7.FrontLeft(OUT)
地址 位数 名称
0008h 0 SSIDOBit0
0008h 1 SSIDOBit1
0008h 2 SSIDOBit2
■8.FrontLeft(IN)
地址 位数 名称
0000h 0 Device No. Bit0
0000h 1 Device No. Bit1
0000h 2 Device No. Bit2
0000h 3 Device No. Bit3
0000h 4 Device Added Information Bit0
0000h 5 Device Added Information Bit1
0000h 6 Device Added Information Bit2
0000h 7 Output Register Value Bit0
0001h 0 Output Register Value Bit1
0001h 1 Output Register Value Bit2
0001h 2 Output Register Value Bit3
0001h 3 Output Register Value Bit4
0001h 4 Input Register Value Bit0
0001h 5 Input Register Value Bit1
0001h 6 Input Register Value Bit2
0001h 7 Input Register Value Bit3
0002h 0 BOARD (F / Right Front) ID0
0002h 1 BOARD (F / Right Front) ID1
0002h 2 BOARD (F / Right Front) ID2
0002h 3 BOARD (F / Right Front) ID3
0002h 4 BOARD (F / Right Front) ID4
0002h 5 BOARD (F / Right Front) ID5
0002h 6 BOARD (F / Right Front) ID6
0002h 7 BOARD (F / Right Front) ID7
0003h 0 BOARD (F / Right Front) ID8
0003h 1 BOARD (F / Right Front) ID9
0003h 2 BOARD (F / Right Front) ID10
0003h 3 BOARD (F / Right Front) ID11
0003h 4 BOARD (F / Right Front) ID12
0003h 5 BOARD (F / Right Front) ID13
0003h 6 BOARD (F / Right Front) ID14
0003h 7 BOARD (F / Right Front) ID15
000Ch 4 SSI DI Bit4
■9.RearLeft(OUT)
地址 位数 名称
0000h 0 CTF(Right Rear) Cover Lock
0000h 1 CTF(Right Rear) Shutter Open
0000h 2 CTF(Right Rear) Setup Switch
0000h 3 CTF(Right Rear) Safety Relay Reset
0000h 4 CTF(Right Rear) Servo ON Permission
0000h 5
CTF(Right Rear) Pallet Height Detection Sensor(L)
Permit
0000h 7
CTF(Right Rear) Pallet Height Detection Sensor(R)
Permit
0001h 0 CTF(Right Rear) Barcode Reader Trigger On
0001h 1 CTF(Right Rear) Barcode Reader Timeout Set Bit0
0001h 2 CTF(Right Rear) Barcode Reader Timeout Set Bit1
0001h 3 CTF(Right Rear) Barcode Reader Timeout Set Bit2
0001h 4
CTF(Right Rear) Barcode Reader Receive Counter
Clear
4-15
4
■10.RearLeft(IN)
地址 位数 名称
0000h 0 Device No. Bit0
0000h 1 Device No. Bit1
0000h 2 Device No. Bit2
0000h 3 Device No. Bit3
0000h 4 Device Added Information Bit0
0000h 5 Device Added Information Bit1
0000h 6 Device Added Information Bit2
0000h 7 Output Register Value Bit0
0001h 0 Output Register Value Bit1
0001h 1 Output Register Value Bit2
0001h 2 Output Register Value Bit3
0001h 3 Output Register Value Bit4
0001h 4 Input Register Value Bit0
0001h 5 Input Register Value Bit1
0001h 6 Input Register Value Bit2
0001h 7 Input Register Value Bit3
0002h 0 BOARD (R) ID0
0002h 1 BOARD (R) ID1
0002h 2 BOARD (R) ID2
0002h 3 BOARD (R) ID3
0002h 4 BOARD (R) ID4
0002h 5 BOARD (R) ID5
0002h 6 BOARD (R) ID6
0002h 7 BOARD (R) ID7
0003h 0 BOARD (R) ID8
0003h 1 BOARD (R) ID9
0003h 2 BOARD (R) ID10
0003h 3 BOARD (R) ID11
0003h 4 BOARD (R) ID12
0003h 5 BOARD (R) ID13
0003h 6 BOARD (R) ID14
0003h 7 BOARD (R) ID15
0004h 0 CTF(Right Rear) Elevator-axis ORG/OR-
0004h 1 CTF(Right Rear) Elevator-axis OR+
0004h 2 CTF(Right Rear) Pallet Transfer Area Sensor
0004h 3 CTF(Right Rear) Shutter Open
0004h 4 CTF(Right Rear) Shutter Close
0004h 7 CTF(Right Rear) Pallet Detect in Stocker
0005h 1 CTF(Right Rear) Pallet Detect on Elevator
0005h 2 CTF(Right Rear) Pallet Middle Position Sensor
0005h 4 CTF(Right Rear) Cover Close
0005h 5 CTF(Right Rear) Cover Lock
0005h 6 CTF(Right Rear) Setup Switch
0005h 7
CTF(Right Rear) Regenerative Resistor Thermal
Sensor
0006h 0 CTF(Right Rear) Hook-axis ORG/OR-
0006h 1
CTF(Right Rear) Hook axis Advanced End Position
Sensor
0006h 2 CTF(Right Rear) Servo ON State
地址 位数 名称
0006h 6 CTF(Right Rear) Pallet Height Detection Sensor(L)
0006h 7 CTF(Right Rear) Pallet Height Detection Sensor(R)
0007h 0
CTF(Right Rear) Barcode Reader Receive Counter
Bit0
0007h 1
CTF(Right Rear) Barcode Reader Receive Counter
Bit1
0007h 2
CTF(Right Rear) Barcode Reader Receive Counter
Bit2
0007h 3
CTF(Right Rear) Barcode Reader Receive Counter
Bit3
0007h 4
CTF(Right Rear) Barcode Reader Receive Counter
Bit4
0007h 5 CTF(Right Rear) Barcode Reader is Sending Data
0007h 6 CTF(Right Rear) Barcode Reader Found No Barcode
0007h 7 CTF(Right Rear) Barcode Reader Receive Complete
