High Speed Multi T ray Feeder STF-100N User ’ s Guide 1 1-38 11.1.7. Palle t Ass’y
Information on A/S Tool & Materials
11-37
No. Part No. Name Q'ty Tape Remark
1 J70651129A Top Cover-STF100N 1 STF-20-550-001A
2 J70651130A Bottom Cover-STF100N 1 STF-20-550-002A
3 J70651131A Left Cover-STF100N 1 STF-20-550-003A
4 J70651132A Right Cover-STF100N 1 STF-20-550-004A
5 J70651133A Front Door2-STF100N 1 STF-20-550-005A
6 J70651134A Rear Door-STF100N 1 STF-20-550-006A
7 J72651005A Tray Guide A-STF100N 4 STF-20-550-007A
8 J71651029A Rail Guide-STF100N 2 STF-20-550-008A
9 J71651030A Handle BKT-STF100N 2 STF-20-550-009A
10 J70651073A Handle3-STF100N 2 STF-20-550-010A
11 J71651031A Position Locator-STF100N 1 STF-20-550-011A
12 J70651209A Magazine Bush-STF100N 1 STF-20-550-012A
13 J70651180A Pin-STF100N 4 STF-20-550-013A
14 J66011015A Ball Bearing 623ZZ-STF100N 1
15 J61071008A Magazine Door Spring-STF100N 2
High Speed Multi Tray Feeder STF-100N User’s Guide
11-38
11.1.7. Pallet Ass’y
Information on A/S Tool & Materials
11-39
No. Part No. Name Q'ty Tape Remark
1 J71651002A Pallet Base-STF100N 1 STF-20-560-001A
2 J72651013A Pallet Connection-STF100N 1 STF-20-560-002A
3 J70651135A Down Plate-STF100N 1 STF-20-560-003A
4 J70651136A Up Plate-STF100N 1 STF-20-560-004A
5 J70651168A Transfer Shaft-STF100N 2 STF-20-560-005A
6 J70651178A Coil Spring-STF100N 2 STF-20-560-006A
7 J70651170A Plate Guide-STF100N 2 STF-20-560-008A
8 J6021000001 Wing-Nut-STF100N 2
9 J02031002A 3M Tape-STF100N 1
