KGB_YV100Xg_PL.pdf - 第11页
6 3 Feeder Floating Detection 20 (After July 2008) Feeder KGB-101 1 Front Back Right FES FES Left Right Left 1 1 28 17 29 25 15 1 9 13 24 1 25 10 26 24 28 6 24 5 27 23 23 27 22 1 9 21 22 29 18 7 8 9 24 16 25 29 24 12 12 …
5
3
Feeder Floating Detection 20 (February 2006 - July 2008)
Feeder
KGB-1011
Front
Back
Right
FES
FES
FES
FES
Left
RightLeft
2
1
1
17
9
11
4
16
6
17
18
5
16
13
19
13
19
14
11
10
17
17
1
16
3
3
3
3
2
1
4
6
18
17
5
16
13
19
14
2
1
1
17
9
11
4
16
8
17
18
5
16
14
11
10
1
16
2
1
4
7
18
17
5
16
13
19
14
12
15
1
12
15
1
12
15
1
12
15
1
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
KGS-M3961-00X SENSOR, LASER ASSY 1
2
KGS-M3951-00X PLATE SENSOR 1
3
KGS-M3910-00X BRACKET SENSOR, 1 1
4
KGS-M3906-00X BRACKET 6
1
5
KGS-M3911-00X SQUARE WASHER
1
6
KGS-M3901-C0X BRACKET SENSOR, 2 1
7
KGA-M3901-E0X BRACKET SENSOR, 2 1
8
KGA-M3901-F0X BRACKET SENSOR, 2 1
9
KGS-M3941-00X
BRACET 4-1 SENSOR 1
10
KGS-M3942-00X
BRACET 4-2 SENSOR 1
11
KG2-M3903-10X
SEAL, LASER 1
12
KGS-M3790-00X
SENSOR BRACKET 1
13
91317-03012 BOLT HEX. SOCKET HEAD
2
14
90115-02J005 BOLT HEX. SOCKET HEAD
2
15
90115-02J006 BOLT HEX. SOCKET HEAD
2
16
91317-04010 BOLT HEX. SOCKET HEAD
4
17
91317-04012 BOLT HEX. SOCKET HEAD
6
18 92907-04200
WASHER PLAIN
4
19 92907-03200
WASHER PLAIN
2
6
3
Feeder Floating Detection 20 (After July 2008)
Feeder
KGB-1011
Front
Back
Right
FES
FES
Left
Right Left
11
28
17
29
25
15
19
13
24
1
25
10
26
24
28
6
24
5
27
23
23
27
22
19
21
22
29
18
7
8
9
24
16
25
29
24
12
12
11
28
13
3
26
25
14
24
23
27
22
17
14
24
20
22
22
29
20
22
22
29
FES
FES
11
28
29
17
25
15
19
13
24
2
25
10
26
24
6
24
5
27
23
23
27
22
19
21
7
8
9
24
16
25
29
17
24
12
12
11
28
13
4
26
25
14
24
23
27
22
14
24
20
22
22
29
20
22
22
29
28
22
29
18
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGS-M3971-00X BRKT. SENSOR1 F 1
2 KGS-M3971-10X BRKT. SENSOR1 R 1
3 KGS-M3972-00X BRKT. SENSOR2 F 1
4 KGS-M3972-10X BRKT. SENSOR2 R 1
5 KGA-M3973-00X BRKT. SENSOR3 1
6 KGS-M3974-00X PLATE SENSOR 1
7 KGA-M3975-00X BRACKET. RECEIVER 1
8 KGS-M3976-00X COVER. SENSOR 1 1
9 KGS-M3977-00X SQUARE WASHER 1 1
10 KGS-M3978-00X SQUARE WASHER 2 1
11 KGS-M3951-00X PLATE SENSOR 2
12 KGS-M3910-00X BRACKET SENSOR, 1 2
13 KGS-M3906-00X BRACKET 6 3
14 KGS-M3911-00X SQUARE WASHER 2
15 KGS-M3941-00X BRACET 4-1 SENSOR R 1
16 KGS-M3942-00X BRACET 4-2 SENSOR R 1
17 KGS-M3961-00X SENSOR, LASER ASSY 1
18 KGS-M3961-10X SENSOR, LASER ASSY 1
19 KG2-M3903-10X SEAL, LASER 1
20 KGS-M3790-00X SENSOR BRACKET 1
21 98907-03005 SCREW,BINDING HEAD 2
22 90115-02J005 BOLT HEX. SOCKET HEAD 6
23 91317-03012 BOLT HEX. SOCKET HEAD 6
24 91317-04010 BOLT HEX. SOCKET HEAD 14
25 91317-04012 BOLT HEX. SOCKET HEAD 12
26 92907-04200 WASHER PLAIN 8
27 92907-03200 WASHER PLAIN 6
28 KGS-M3962-00 SENSOR, TRANSMITTER 1
29 KGS-M3963-00 SENSOR, RECEIVER 1
7
3
Feeder Floating Detection 50 (Before August 2008)
Feeder
KGB-081015
Front
Rear
Non Stop
Feeder Type
9
4
1
3
8
7
5
10
Non Stop
Feeder Type
11
9
4
2
3
8
7
6
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M3901-00X BRACKET SENSOR, 2 1
2 KV7-M3901-10X BRACKET SENSOR, 2 1
3 KV7-M3910-01X BRACKET SENSOR, 1 1
4 KG7-M3906-00X BRACKET 6 2
5 KV7-M3905-20X BRACKET 2, SENSOR 1
6 KV7-M3905-30X BRACKET 2, SENSOR 1
7 KV7-M3907-00X BRACKET 3, SENSOR 1
8 KG9-M3455-30X SENSOR S 1
9 KH5-M3456-30X SENSOR R 1
10 KV7-M3901-20X BRACKET SENSOR, 2 1
11 KV7-M3901-30X BRACKET SENSOR, 2 1
