7-3 Service Part List
7-2
User's Guide For Tape Feeder Calibration Jig
NO. PART NO. PART NAME Q'TY REMARK
1 FC28-000168 RUBBER LEG 4
2 FC15-004764A PANEL EDGE 1
3 FC14-002137 USB2USB HOLDER 1
4 FC28-000180 KNOB 2
5 FC05-001195A BASE-C 1
6 J90991065A CE ROHS PLATE ASSY 1
7 AM03-021347A SME FEEDER BASE ASSY-C 1
8 FC15-004762A FEEDER BOARD COVER-C 1 Cover
9 FC15-004765A PANEL SIDE-C 1
10 FC29-007787A UPPER BASE SUPPORT-C 3
11 FC15-004766A PANEL SMPS 1
12 AM03-021620A UPPER BASE COVER ASSY 1
13 EP12-001004 MIRROR BOX 1
14 EP13-001028 SME8 JIG COAXIAL LIGHT 1
15 EP14-001017 COAXIAL LENS-C 1
16 PT02-001033 CAMERA-C 1
17 FC09-007331A CAMERA BRACKET-C 1
18 AM03-001101 XYZ STAGE-C 1
19 FC05-001196A UPPER BASE-C 1
7-3
Service Part List
7-4
User's Guide For Tape Feeder Calibration Jig
NO. PART NO. PART NAME Q'TY REMARK
20 AM03-020515A SMPS SWITCH CABLE ASSY-C 4
21 AM03-020517A FIDUCIAL LIGHT CABLE ASS'Y 1
22 AM03-020516A COAXIAL LIGHT CABLE ASS'Y 1
23 EP16-002162A FEEDER BASE BOARD 1SLOT 2
Board
24 AM03-020518A FEEDER SMPS/CAN CABLE ASSY-C 1
25 EP10-003281 5PIN2USB GENDER 1
26 EP10-003239 CAN PRO-C 3
27 AM03-020514A FEEDER CAN CABLE ASSY-C 1
28 EP06-001071 SMPS-C 1
29 AM03-020513A FEEDER SMPS CABLE ASSY-C 3
30 FC15-000883A FIDUCIAL DIFFUSER 1
31 AM03-012380A BOARD-FIDUCIAL-ILL 1
70 FC29-900605 HEX SUPPRORT 3 M3L10B5
71 FC29-900554 HEX SUPPRORT 4 M3L7B5
72 FC18-903189 TIE MOUNT 7
73 FC18-902827 FLAT HEAD SOCKET SCREW 11 M3L8
74 FC18-902809 BUTTON HEAD SOCKET SCREW 16 M4L12
75 FC18-902806 BUTTON HEAD SOCKET SCREW 16 M3L6
76 FC18-902765 SOCKET HEAD CAP SCREW 4 M5L30
77 FC18-902761 SOCKET HEAD CAP SCREW 11 M5L20
78 FC18-902745 SOCKET HEAD CAP SCREW 10 M4L15
79 FC18-902748 SOCKET HEAD CAP SCREW 2 M4L20
80 FC18-902757 SOCKET HEAD CAP SCREW 1 M5L15
81 FC18-901902 BUTTON HEAD SOCKET SCREW 3 M3L8
82 FC18-901892 BUTTON HEAD CAP SCREW 2 M2.5X6
