KY8030 Programmers Manual.pdf - 第68页
66 | KY-8030 Series (KYOS-2007001_rev0) 3D In ‐ line Solder Paste Inspection Systems
Programmers Manual
| 65
● Example files
@HEADER
Version=7
Unit=MM
Coordinate=LL
OffsetX=0.000000
OffsetY=0.000000
Arrays=4
Fiducials=3
CheckPoints=0
Patterns=36
Pads=230
@BOARD
169.999700 249.999500
@ARRAY
1 0.000000 0.000000 0
2 53.500000 0.000000 0
3 0.000000 48.400000 0
4 53.500000 48.400000 0
@FIDUCIAL
1 G C 4.999100 28.199100 1.551200 1.551200 0.000000 0.000000
""
2 G C 150.000000 5.001300 1.551200 1.551200 0.000000 0.000000
""
3 G C 24.999000 245.000800 1.551200 1.551200 0.000000 0.000000
""
@CHECKPOINT
@PATTERN
1 R 0.850800 0.950000 0.000000 0.000000 0.8082600000 0.000
2 R 0.950000 0.850800 0.000000 0.000000 0.8082600000 0.000
3 R 1.300400 0.850800 0.000000 0.000000 1.1063800000 0.000
4 R 0.680600 0.500400 0.000000 0.000000 0.3405720000 0.000
5 U 0.778600 0.778600 0.000800 0.000000 0.3020520000 0.000
6 U 1.994500 2.024200 -0.025100 0.001600 1.9923950000 0.000
7 U 2.064100 1.958600 0.004400 -0.025300 1.9897060000 0.000
8 U 1.260400 1.519000 -0.002100 0.001300 1.1010880000 0.000
9 U 1.023600 1.082200 0.001000 0.000000 0.5860920000 0.000
10 U 1.023600 1.082200 -0.001200 0.001800 0.5858900000 0.000
@PAD
1 1 24.125000 12.700000 “”
2 1 24.125000 11.400000 “”
3 1 28.775000 11.450000 “”
4 1 28.775000 12.750000 “”
5 1 28.775000 10.150000 “”
6 1 27.225000 11.700000 “”
7 1 27.225000 10.400000 “”
8 1 27.225000 13.000000 “”
9 1 25.675000 11.950000 “”
10 1 25.675000 10.650000 “”
11 1 25.675000 13.250000 “”
12 2 27.525000 14.600000 “”
13 2 28.825000 14.600000 “”
14 2 26.225000 14.600000 “”
15 3 33.925000 41.200000 “”
16 3 33.925000 43.200000 “”
17 4 38.165000 40.400000 “”
18 4 38.165000 41.200000 “”
19 4 36.585000 41.200000 “”
@END
66 | KY-8030 Series(KYOS-2007001_rev0)
3DIn‐lineSolderPasteInspectionSystems
Programmers Manual
| 67
2. CEditor
2.1. Program Structure
2.1.1. Data Flow Diagram
The CEditor program lets you to set the inspection tolerance and to group a series of
pads into a part and assign a part name and component ID to it for easier management
of pad files. In addition to the job file editing function of the 3D Inspector, the CEditor
program allows you to edit a pad or CAD file and save it into a job file for effective
management.
GerbPad
:Retrieve
Pad Data
Job File
*.gpd
Gerber File
*.gbr
CEditor
:Modify Pad File and
Project File
3D Inspector
:PCB Inspection
Pad File
*.pad
Project File
*.mdb
KY-3030 Series
CAD File
*.txt,*.asc
