PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview
Part No. 4005.00.906 1-4
1.3 Warranty
Air-Vac Engineering Company warrants its equipment for a period of one (1) year from date of shipment on all
parts, materials and labor costs required to repair the system except for component parts that are considered
“wear and tear” items which are warranted for ninety (90) days. These include, but are not limited to, heaters,
belts, lights, vacuum cups and tubing.
Air-Vac agrees to repair or replace any or all such equipment that may prove to be defective within the warranty
period, without expense, excluding shipping to the owner. This warranty shall not apply to any products that have
been repaired or altered except by Air-Vac Engineering.
Services under warranty shall not affect an extension of the warranty period, nor will a new warranty period be
granted for the parts, which were replaced/repaired. The title of the replaced parts will automatically pass to Air-
Vac.
Air-Vac reserves the right to reject replacement under this warranty where, in the sole opinion of Air-Vac, the
defect is due to obvious misuse and/or improper maintenance of the module or any part thereof.
The express and/or implied warranty of Air-Vac is limited to the replacement and/or repair of any item defective in
material and/or workmanship. Other damages, if any, direct or consequential are expressly excluded from this
warranty.
Air-Vac shall be liable under this warranty only if 1) Air-Vac receives notice during the appropriate warranty period
(90 days or 1 year as applicable); 2) The products are operated in accordance with the supplied documentation;
and 3) Such products are, to Air-Vac’s satisfaction, determined to be defective.
When contacting Air-Vac for warranty inquiries, please provide the following information:
Order number which the parts were shipped
Model and serial number of the product
Reason for warranty
Products cannot be returned to Air-Vac without authorization – please call for an RMA #.
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview
Part No. 4005.00.906 1-5
1.4 Material Check List - PCBRM15
The following ‘Machine Section’ is a checklist of items shipped with all PCBRM15 units.
MACHINE TOOL KIT - 12050 SERIAL NUMBER#
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Sleeve Baffle
1
2004.01.102
Extractor Tool
1
EX-2
Set of fuses (packed in small plastic case):
- 15 amp
- 1/2 amp
- 3/4 amp
- 3/10 amp
1
2
2
2
2
9002.04.043
9002.04.038
9002.04.035
9002.04.040
5/32” Tee Handle Allen Wrench
1
12050B
1/4” Spintite Sprocket Wrench
1
12050A
Graphite Anti-Sieze
1
AS15
Bubble Level
1
12015
Allen Wrench Set
1
12055
3mm Allen Wrench
1
12050L
MACHINE ACCESSORIES
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Footswitch
1
12870
Bailer
1
SL5
Pot Cover
1
2004.01.108
Manual
1
2004.00.900
Ladel
1
9008.99.315
Spatula
1
9008.99.314
Gloves (pair)
1
12050M
SPARE PARTS
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Sleeve Baffle
1
2004.01.102
Pump Assembly
1
2004.01.040
Drive Belt (Hi Temp)
1
12467
Pump Bearings (set of 2)
1
9001.09.020
Thermocouple & Fitting (Process Temp.)
1
12801
Thermocouple & Fitting (Over Temp.)
1
12802
Temperature Controller (Process)
1
12860
Cycle Controller Board
1
12862
Solid State Relay, Pot
1
12865
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview
Part No. 4005.00.906 1-6
1.5 Material Check List - PCBRM System 5.2
The following ‘Machine Section’ is a checklist of items shipped with all PCBRM Systems.
MACHINE TOOL KIT - 12050 SERIAL NUMBER#
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Sleeve Baffle
1
12011
Extractor Tool
1
EX-2
Set of fuses (packed in small plastic case):
- 15 amp
- 1/2 amp
- 3/4 amp
- 3/10 amp
1
2
2
2
2
9002.04.043
9002.04.038
9002.04.035
9002.04.040
5/32” Tee Handle Allen Wrench
1
12050B
1/4” Spintite Sprocket Wrench
1
12050A
Graphite Anti-Sieze
1
AS15
Bubble Level
1
12015
Allen Wrench Set
1
12055
3mm Allen Wrench
1
12050L
Spatula
1
9008.99.314
MACHINE ACCESSORIES
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Footswitch
1
12870
Bailer
1
SL5
Pot Cover
1
12590
Manual
1
3006.00.903
Ladel
1
9008.99.315
Gloves (pair)
1
12050M
SPARE PARTS
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Sleeve Baffle
1
12011
Pump Assembly
1
12401
Drive Belt (Hi Temp)
1
12467
Pump Bearings (set of 2)
1
9001.09.020
Thermocouple & Fitting (Process Temp.)
1
12801
Temperature Controller (Process)
1
12802
Cycle Controller Board
1
12862
Solid State Relay, Pot
1
12865
