PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview Part No. 4005.00.906 1- 7 1.6 Unpacking - PCBRM15 Shipping Weight: - 170 lbs. Shipping Dimensions (W x D x H): - 43” x 34” x 30” IMPORTANT!! D…
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview
Part No. 4005.00.906 1-6
1.5 Material Check List - PCBRM System 5.2
The following ‘Machine Section’ is a checklist of items shipped with all PCBRM Systems.
MACHINE TOOL KIT - 12050 SERIAL NUMBER#
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Sleeve Baffle
1
12011
Extractor Tool
1
EX-2
Set of fuses (packed in small plastic case):
- 15 amp
- 1/2 amp
- 3/4 amp
- 3/10 amp
1
2
2
2
2
9002.04.043
9002.04.038
9002.04.035
9002.04.040
5/32” Tee Handle Allen Wrench
1
12050B
1/4” Spintite Sprocket Wrench
1
12050A
Graphite Anti-Sieze
1
AS15
Bubble Level
1
12015
Allen Wrench Set
1
12055
3mm Allen Wrench
1
12050L
Spatula
1
9008.99.314
MACHINE ACCESSORIES
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Footswitch
1
12870
Bailer
1
SL5
Pot Cover
1
12590
Manual
1
3006.00.903
Ladel
1
9008.99.315
Gloves (pair)
1
12050M
SPARE PARTS
DESCRIPTION
QUANTITY
PART NUMBER
CHECK
Ö
Sleeve Baffle
1
12011
Pump Assembly
1
12401
Drive Belt (Hi Temp)
1
12467
Pump Bearings (set of 2)
1
9001.09.020
Thermocouple & Fitting (Process Temp.)
1
12801
Temperature Controller (Process)
1
12802
Cycle Controller Board
1
12862
Solid State Relay, Pot
1
12865
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview
Part No. 4005.00.906 1-7
1.6 Unpacking - PCBRM15
Shipping Weight: - 170 lbs.
Shipping Dimensions (W x D x H): - 43” x 34” x 30”
IMPORTANT!!
DO NOT LIFT OR PULL HERE AT POINTS INDICATED,
DAMAGE TO SYSTEM MAY RESULT.
− Position module on a level surface which can provide adequate support for weight.
− Accessories are normally shipped in box with module. Please inspect carefully and check that
all items have been shipped.
− Save shipping box for any future shipping.
X
X
X
PCBRM15 & PCBRM System 5.2 User’s Manual Chapter 1: Introduction/Overview
Part No. 4005.00.906 1-8
1.7 Unpacking - PCBRM System 5.2
Shipping Weight: - 250 lbs.
Shipping Dimensions (W x D x H): - 67” x 35” x 52”
IMPORTANT!!
SUPPORT MUST BE PROVIDED IN CENTER. BASE PLATE WILL BEND. LIFT MACHINE WITH A
FORK LIFT AS SHOWN.
DO NOT LIFT OR PULL HERE.
DAMAGE TO SYSTEM MAY RESULT.
− Position module on a level surface which can provide adequate support for weight.
− Accessories are normally shipped in box with module. Please inspect carefully and check that
all items have been shipped.
− Save shipping box for any future shipping.
Lift Here
With Fork Lift
X
X
X
X
X
Fork
Fork
support
