4 Configuration Installation and Configuration Guide SIPLACE Exp lorer 4.1 Standard Monitoring Application (SMA) Edition 11/2020 EN 50 4 Fig. 4 - 1 1 Step 5: configure system database  After entering the dat abase acces…

Installation and Configuration Guide SIPLACE Explorer 4 Configuration

Edition 11/2020 EN 4.1 Standard Monitoring Application (SMA)

4.1.1.6 Step 5 - Configure System Database

 Now you can configure the SIPLACE Explorer system database settings:

– MS SQL Server instance:port number

You can add the port number to the SQL Server instance, separated by a colon, for

example: PLK0495A\SIPLACE_2005EXPR:12345.

– Database name

– User Name

–Password

 If you have imported a production line from the OIS the SIPLACE Explorer database settings

are automatically adopted.

NOTE

Click on the Browse for SQL instances icon. All SQL server instances available will be

shown in the Select SQL Server instance dialog box.

If the Select SQL Server instance dialog box shows no entries, you need to specify the SQL

server instance manually in the MS SQL Server field. You can add the port number to the

SQL Server instance, separated by a colon, for example:

PLK0495A\SIPLACE_2005EXPR:12345. 4

4 Configuration Installation and Configuration Guide SIPLACE Explorer

4.1 Standard Monitoring Application (SMA) Edition 11/2020 EN

Fig. 4 - 11 Step 5: configure system database

 After entering the database access parameters, we strongly recommend that you check the

connection to the database. Click Test to check whether the connection to the database can

be established.

 If the connection does not function properly, you will see the following information box:

Fig. 4 - 12 DB error

 Click on the Setup DB Connection button to start the DB Connection Wizard setup

sequence and configure the SIPLACE Explorer system database. Follow the instructions at

“Database Connection Wizard” on page 80.

Installation and Configuration Guide SIPLACE Explorer 4 Configuration

Edition 11/2020 EN 4.1 Standard Monitoring Application (SMA)

 If the connection functions properly, you will see the following information box:

Fig. 4 - 13 Success

 Click OK. The system will check the database data. If the database has data from SIPLACE

Explorer 2.0 - 3.10, you will need to convert the database for SIPLACE, due to the changed

data structure in the SIPLACE Explorer 3.11 database. In this case, the Convert Database

dialog box will open.

NOTE

Consider the following when converting the database

- You require database administrator privileges.

- Once you have started the conversion, this process can not be stopped.

- The conversion time depends on the size of the database and the performance of the

computer. It may take up to one hour. 4

 Specify the access data for the database administrator and enable the Backup database

option.

 Confirm your entries with OK. The DB backup location dialog box will open

Fig. 4 - 14 DB backup location

 Before performing the conversion, the system creates a backup file of the database. Specify

the folder for this file in the Folder for database backup field. Click on the Browse ...
