番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1CSSX0166 1 SLIDE, X-AXIS ｽﾗｲﾄﾞ X軸
2WSX4021 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
3WSX4030 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
4WSX4040 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
5WSX4082 1 COVER ｶﾊﾞｰ
8CSSY0110 2 TUBE ﾁｭｰﾌﾞ
9CSSX0230 1 BKT BKT X146∼
10WSX4141 1 BKT BKT
11WSX4150 3 BKT BKT
12CSSX0200 1 BKT BKT X36∼
13CSSX0170 1 RETAINER, RAIL 押え ﾚｰﾙ
15CSSX0181 1 GUIDE ｶﾞｲﾄﾞ
16CSSX0240 1 BKT BKT X156∼
17CSSX0150 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
19WSX4260 1 COLLAR ｶﾗｰ
20CSSX0123 1 BKT, MOTOR BKT ﾓｰﾀ 注2. Note.2
21CSSX0141 1 COVER, BEARING 蓋 ﾍﾞｱﾘﾝｸﾞ
22CSSX0133 1 BKT, SUPPORT BKT 支え 注2. Note.2
24WSX4320 2 COVER 蓋
25WSX4390 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ
26WSX4400 2 BOLT ﾎﾞﾙﾄ
27SAM1482 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ
28H4161A 1 BEARING ﾍﾞｱﾘﾝｸﾞ 25TAC62BDB
29N1026A 1
NUT, LOCK
ﾅｯﾄ ﾛｯｸ ZM025
30H4206H 1
BEARING
ﾍﾞｱﾘﾝｸﾞ 60/22ZZ
32K4138X 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ 25005-075-27-2050
33CSSX0080 1 BKT, STOPPER BKT ｽﾄｯﾊﾟ
34WSX4511 2 STOPPER ｽﾄｯﾊﾟ
35CSSX0090 4 COLLAR ｶﾗｰ
36GPT0792 20 RETAINER 押え
37GPT0891 3 BKT, SW BKT SW
38Y3067A 2 UNION ﾕﾆｵﾝ KQ2H06-00
39CSSX0100 4 WASHER ﾜｯｼｬ
40H2075A 2 PIN, TAPER ﾋﾟﾝ ﾃｰﾊﾟ 6ﾟX45L
41S4040X 1
SENSOR, PHOTO
ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A
42S4040Z 2
SENSOR, PHOTO
ｾﾝｻ ﾌｫﾄ EE-SPX406-W2A
7.Ｘスライド Ｘ Slide (CSSX)
CP-643ME PARTS LIST ver04
7-2
7.Ｘスライド(CSSX)
7.Ｘ Slide(CSSX)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
43WSD0620 2 SPACER ｽﾍﾟｰｻ t=1.00 注1. Note.1
44H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
45H5288A BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
46H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
47H5292A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X20L
49H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
50H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
51H5304A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X25L
52H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L
53H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L
54H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L
55H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L
57H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X25L
58H5343A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X30L
59W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
60W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
61W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
62W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
63W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
64W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
65W1045A
WASHER, FLAT
ﾜｯｼｬ 平
4W-6
67W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
68W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
69W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H
70N4035A SCREW, HEX SOCKET SET ﾈｼﾞ六角穴止め 4MX20L
71K5173A
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋
M3X10L
72N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7
73CSSX0190 1 CATCH PAN 受け 皿
74WSX4420 1 HOLDER ﾎﾙﾀﾞ
75CSSX0061 1 HOLDER ﾎﾙﾀﾞ
76CSSX0053 1 CATCH PAN 受け 皿
77CSSX0030 2 COVER, SCREW ｶﾊﾞｰ ｽｸﾘｭｳ
78. SCREW, HEX SOCKET SET ﾈｼﾞ六角穴止め M4X15L
80WSX4460 2 BKT BKT
83WSX4491 1 BKT, STOPPER BKT ｽﾄｯﾊﾟ
84WSX4500 1 STOPPER ｽﾄｯﾊﾟ
7.Ｘスライド Ｘ Slide (CSSX)
CP-643ME PARTS LIST ver04
7-3
7.Ｘスライド(CSSX)
7.Ｘ Slide(CSSX)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
85IPB0431 6 COLLAR ｶﾗｰ
86K5209A SCREW, TRUSS 小ﾈｼﾞﾄﾗｽ M4X8L
87H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L
89CSSX0210 1 BKT, CLAMP BKT ｸﾗﾝﾌﾟ X140∼
90CSSX0220 1 BKT, CLAMP BKT ｸﾗﾝﾌﾟ X140∼
91H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L
92H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
93CSWZ0110 1 BKT BKT X36∼
注1.(仕様選択部品) WSD0710(t=0.95),WSD0720(t=1.05),WSD0730(t=1.10),WSD0740(t=0.975),WSD0750(t=1.025)
Note.1 : (Specified part selection) WSD0710(t=0.95),WSD0720(t=1.05),WSD0730(t=1.10),WSD0740(t=0.975),WSD0750(t=1.025)
注2.(20)BKTﾓｰﾀと(22) BKT支えは組み合わせ部品ですので同時に交換してください｡
Note.2 :The bkt motor No.20 and the bkt support No.22 are used as set.
If the replacement of one of the bkt is necessary both must be replaced.
