ELIMINATE SOLDER VOIDS ELIMINATE SUBSTRATE WARPAGE ELIMINATE CHANGEOVER TIME The Global Standard of Excellence for Solder Reflow
Speed
Controller
Pressure
Transducer
CLOSED LOOP
CONVECTION CONTROL
THE KEY TO REPEATABILITY
ADVANCED FLUX
MANAGEMENT TECHNOLOGY
• 90% flux removal efficiency
• No condenser to clean
• Cuts Cost of Ownership in half
FOR SMT REFLOW, CURING
AND SEMICONDUCTOR
PACKAGING APPLICATIONS
The Pyramax series of reflow ovens
sets the industry standard for thermal
performance, providing electronics
manufacturers with the highest
hroughput, and increased flexibility to
compete successfully in today’s
challenging global marketplace.
Closed Loop Convection
BTU‘s exclusive Closed Loop Convection Control
provides maximum flexibility in process control.
• Side-to-side recirculation enhances temperature uniformity
• Guaranteed process repeatability, system-to-system,
site-to-site
• Unmatched convection efficiency reduces zone
temperature setpoints
The Global Standard of
Excellence for Solder Reflow
• SUPERIOR THERMAL PERFORMANCE
• ADVANCED FLUX MANAGEMENT
• LOW COST OF OWNERSHIP
THE INDUSTRY’S BEST PERFORMING REFLOW OVEN
ELIMINATE SOLDER VOIDS
ELIMINATE SUBSTRATE WARPAGE
ELIMINATE CHANGEOVER TIME
The Global Standard of
Excellence for Solder Reflow
Wincon™ is an advanced windows-based
software system for controlling the
operation of BTU thermal processing equipment. Wincon combines
both the simplicity of a graphical user interface with powerful
diagnostic and analytical tools. Wincon is used in conjunction with
BTU’s proprietary Intellimax controller on all BTU systems, including
the Pyramax family of convection reflow ovens.
POW ERED BY
• Automatic recipe
generator
• Reduces oven
set-up time
• Exclusive convection
rate algorithm
• Automatically reduces
reflow oven
operating costs
• Takes advantage of
idle time
• Quick recovery
using SMEMA or
remote sensor
• Redundant process
monitor
• Enables product
traceabilty when used
with a barcode reader
• Fully integrated
with MES/factory
communication
• Reduces peak power
usage allowing for
lower connected load
• Optimizes power use
automatically within an
overall given %
• Allows for fastest
start-up/response while
total power is limited
• CFX (Connected Factory
Exchange) is a message
system to the CFX host
• Provides vertical messaging
on machine data
• Complimentary to the
IPC-Hermes horizontal
communication standard
• Machine-to-machine
communication/horizontal (M2M)
• Improves board flow
management and traceability
through all stations of SMT line
• Complimentary with IPC-CFX
vertical communication standard
The Industry’s Most Powerful Oven Control System
INDUSTRY
4.0 READY
BTU is ready for Industry 4.0 and
offers many solutions today:
• Custom MES Interface
• SECS/GEM
• OPC
• REST/JSON/MQTT
