C-S229-03, 04 Application for High Speed H-Axis INSTRUCTION MANUAL SPECIAL SPECIFICA TIONS Read this instruction manual carefully and keep it at hand. • • • • • Before operating the machine, read these safety instruction…
C-S229-03, 04
Application for High Speed H-Axis
INSTRUCTION MANUAL
SPECIAL SPECIFICATIONS
Read this instruction manual carefully and keep it at hand.
••
••
• Before operating the machine, read these safety instructions
carefully and fully understand them.
••
••
• Always keep this instruction manual carefully at hand to refer
it anytime and anywhere.
TCM-X210 Series
This instruction manual can be used only for the machines whose
rating plates have manufacturing Nos. that end with “D”.
Before Use
We are grateful to you for purchasing these special specified
products.
Please keep in mind the following items before use.
1. Please read this instruction manual carefully for correct use of
these special specified products.
2. Explained in this manual are only the items different from
those in the instruction manual of the main machine.
Use the instruction manual of the main machine together
with this manual.
3. The contents of this manual are subject to change without
prior notice.
Please contact our marketing department or sales ageny for
the detailed information on these special specifications.
This manual is made of recycled paper.
0312-001 1 Tg0989-PM-SO
SOM-1769-001
Application for High Speed H-Axis
C-S229-03, 04
INSTRUCTION MANUAL
SPECIAL SPECIFICATIONS
TCM-X210 Series
Contents
Page
0312-001 2
Tg0989-PM-SO
Before Use ................................................................................................... 1
Contents ....................................................................................................... 2
1. Scope ..................................................................................................... 3
2. Specifications ......................................................................................... 3
3. Component ID Table .............................................................................. 5
3.1 Resistor (R) .................................................................................... 5
3.2 Capacitor (C) .................................................................................. 9
3.3 Coil (L) ............................................................................................ 18
3.4 Filter (FL)........................................................................................ 20
3.5 Diode (DI) ....................................................................................... 21
3.6 Transistor (TR) ............................................................................... 24
3.7 IC (IC)............................................................................................. 29
3.8 Semi-Fixed Variable Resistors (VR) .............................................. 32
3.9 Light Emitting Diode (LED) ............................................................ 35
3.10 Trimmer Capacitor (TC) ................................................................. 36
3.11 Connector (CN) .............................................................................. 37
3.12 Switch (SW) ................................................................................... 41
3.13 Oscillator (CSA) ............................................................................. 42
3.14 Others (ETC) .................................................................................. 43
