Revolver head S15 (booster compatible)
Page 18 / 20 18.11.2021
Pos. Item no. Description Part marking
157 00313997S05 NOZZLE TYPE 614 Wear Part
158 00201559S02 BRAKE FOR SEGMENT V. II
159 00201563S01 PRESSURE SPRING 0,16X1X7,8
00315253-03 SIPLACE CLEANING-TISSUE CONSUMABLE
00315262-01 EGRA PIPE CLEANER CONSUMABLE
160 00116015S01 CRDL-MEASURING DEVICE
SIPLACE80S VARI. NOZZLE
161 00116410-01 CRDL MEASUREMENT SYSTEM FOR
SIPLACE 80F
162 00116040S01 CRDL-MEASURING-HEAD SIPLACE
00116041S01 CRDL-MEASURING-UNIT SIPLACE
163 00308364-02 RLCD MEASURING CABLE
164 00343821S01 CENTERING STATION F.CERAMIC
NOZZLE G4.3
00315259-02 CENTERTING STATION, BASIC TYPE
(NO TONGS
165 00300097-02 HOUSING
166 00300062-01 LEVER (Z) FOR JAWS SP120 G3
167 00300063-01 GUIDE, PREMOUNTED
168 00300081S01 PIN FOR SP120 (G3 PART 15)
169 00300030S01 BALL BEARING D=1,5/D=4/B=2
ULZ 154X
170 00314620S06 H-LEVER
171 00304153-01 BALL BEARING 2*6*2,3 RX206X
172 00300077S01 ADJUSTING SHIM 2X3,5X0,1
173 00300064-01 JAW-Z, MOUNTED
174 00300083-01 JAW FOR LEWER INSULATED
175 00300084S01 PIN FOR SP120 (G2 PART9)
176 00304141S01 SPHERICAL LINER 4*8*10 L 408 X
177 00300085-02 METALL
178 00300065-01 H-JAW
179 00300086S01 PIN FOR SP120 (G2 PART 10)
180 00304141S01 SPHERICAL LINER 4*8*10 L 408 X
181 00300036-01 STOPPER
182 00300037-01 PROXIMITY SWITCH MOUNT
183 00300038-01 SWITCH ACTUATING
Revolver head S15 (booster compatible)
Page 19 / 20 18.11.2021
Pos. Item no. Description Part marking
184 00315257S01 STOPPER SHEEN
185 00300040S01 PIN FOR SP120 (OLD VERSION: G2
PART11)
186 00315363-01 BUSH
187 00300042-01 AXIS
188 00315362S01 BALL BEARING
189 00300043S01 GUIDE SHAFT
190 00304140S01 PRESSURE SPRING FOR CENTERING
STATION D=2/L=11,1
191 00315824S02 TOOTHED STRIP MOUNT G4
192 00304139S01 TENSION SPRING F.CENTERING-
ST.D =4/L=27,2
194 00300114S01 BALL GUIDANCE BSP 10 35 SL
195 00303485S01 TENSION SPRING
196 00303087S01 TOOTHED BAR
00300046-03 TOOTHED WHEEL
00300117-01 O-RING
199 00300045S02 BRAKE SHEET
200 00300047S01 BRAKE UNIT
201 00300049-03 CABLE HOLDER
202 00300030S01 BALL BEARING D=1,5/D=4/B=2
ULZ 154X
203 00303945S01 PROXIMITY SWITCH INDUCTIVE
204 00300123-01 DC SERVO MOTOR
205 00311486S01 CABLE MEASURING JAWS FOR
CENTERING STATION
206 00300051S01 CONTACT LEVER FOR SP120
207 00343823-01 JAW,"Z"FOR CERAMIC/VECTRA
NOZZLES
208 00343822-01 JAW,"H"FOR CERAMIC/VECTRA
NOZZLES
210 00300418-03 CAMERA CABEL COMPONENT
CAMERA
211 00316196-01 CONTROL CABLE FOR OPT. MODULE
19X25
212 00300374-01 CABLE-CONVERSION BOARD
VACUUM BOARD
213 00300408-01 CABLE: CONVERSION BOARD - SP-
HEAD
