MEMO
G -S022-03
1012-003
11
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
401 6301333106 VALVE 2 -Y0842
803N-A210160-A001
225C0125
402 6301106083 PIPE FITTINGS 2
803N-A210160-A002
225F0467
403 6300036534 AIR LINE EQPT 4
803N-A210160-A003
225B0059
404 6300482935 AIR LINE EQPT 4
803N-A210160-A004
225B0251
405 6301328188 BRACKET 2
803N-A210160-A005
211F9195
419 6301426051 BRACKET 1
803N-A210160-A019
211F9048
420 6301319117 BRACKET 1
803N-A210160-A020
211F9049
421 6301339054 BRACKET 1
803N-A210160-A021
211F9368
423 6301164915 PIPE FITTINGS 2
803N-A210160-A023
225F0504
426 6301350226 LEVER 2
803N-A210160-A006
216S2771
427 6301335162 PIN,LOCATE 4
803N-A210160-A007
216E1533
428 6301448992 BRACKET 2
803N-A210160-A008
211F9301
429 6301335681 SPRING,FLAT 2
803N-A210160-A009
222Q0130
430 6301337203 BRACKET 2
803N-A210160-A010
211F9347
431 6301319148 GUIDE,LINEAR 2
803N-A210160-A011
222L0728
432 6301256474 BUSH,BEARING 2
803N-A210160-A012
222A0151
433 6300305678 BUSH,BEARING 4
803N-A210160-A013
222A0072
434 6301333113 MACHINE SCREW 2
803N-A210160-A014
221D0177
435 6301333120 CAM FOLLOWER 2
803N-A210160-A015
222H0137
436 6301319131 ROD END 2
803N-A210160-A016
222B0102
437 6301319155 CYLINDER 2
803N-A210160-A017
224C0559
438 6300465556 PIPE FITTINGS 4
803N-A210160-A018
225C0125
442 6300009101 SET SCREW 2
803N-A210160-A022
221C0100
444 6300009118 SET SCREW 2
803N-A210160-A024
221C0024
451 6300007664 BOLT,HEX-SCT 1 M4X20 221A0021
452 6300007701 BOL
T,HEX-SCT 1 M4X40 221A0025
453 6300007732 BOL
T,HEX-SCT 4 M5X8 221A0028
454 6300007749 BOL
T,HEX-SCT 4 M5X10 221A0029
455 6300007756 BOL
T,HEX-SCT 1 M5X12 221A0030
456 6300007763 BOL
T,HEX-SCT 1 M5X16 221A0031
457 4110418908
SCR PAN 3X6 4 M3X6 PAN 221E0497
461 41
10864408 WASHER SPR 3 4 SW3 F 221H0280
462 411
1412905 WASHER SPR 4 1 SW4 221H0284
463 411
1416705 WASHER SPR 5 10 SW5 221H0287
466 411
1191909 WASHER V 3X7X0.5 4 FW3 F 221H0311
467 41
11414008 WASHER V 4X9X0.8 1 FW4 221H0315
468 411
1414107 WASHER V 5X10X1 10 FW5 221H0318
471 6301297057 BOL
T,HEX-SCT 12 M1.6X3 221AA330
472 6301354323 BOL
T,HEX-SCT 2 M2X3
473 6300007503 BOLT
,HEX-SCT 4 M3X6 221AA005
474 6300007527 BOL
T,HEX-SCT 2 M3X10 221AA007
475 411
1409905 NUT HEX 3 2 M3 221F0079
476 411
1412608 WASHER SPR 2 2 SW2 221H0277
477 411
1412806 WASHER SPR 3 2 SW3 221H0281
N-5
MEMO
G -S022-04
0909-002
13
G -S022-04(L�R)
G -S022-04(L
→
R) G -S022-04(L
→
R)
基板位置決めストッパ
P.C.B. Positioning Stopper
