Sonix
®
954 CRD
TECHNICAL DATA SHEET
5
www.dct.cleaning
Power supply 400V, 32A, 50Hz (3+N+PE) UL 400V, 32A, 60Hz* (3+N+PE)
Pmax 15 kW 15 kW
Compressed air connection Pipe Ø 6 mm Pipe ID 0.24 in
Recommended working pressure 4,5 – 6 Bar 65.25 – 87 PSI
Compressed air quality 3. Class ** 3. Class **
Exhaust pipe diameter Ø 100 mm ID 3.94 in
Exhaust pipe capacity 580 m
3
/h 20450 ft
3
/h
Minimum liquid for  rst run 2 x 100 l 2 x 26.4 gal
Service space required around the device 600 mm 23.6 in
* When using frequency convertor
** According to the norm ISO 8573-1
INSTALLATION REQUIREMENTS
FRONT
VIEW
LEFT
VIEW
BACK
VIEW
140 mm
5.51 in
535 mm
21.1 in
190 mm
7.48 in
discharge of the fluids G 1“
2350 mm
92.5 in
1710 mm
67.3 in
Ø 100 mm
ID 3.94 in
1180 mm
46.5 in
input el. power 400/230 V
input air pressure Ø 10 mm
input air pressure ID 0.39 in
metric units imperial units
Sonix
®
954 CRD
TECHNICAL DATA SHEET
6
www.dct.cleaning
1 process chambers – fully automatic solution
100% closed loop uid system
Cleaning and rinsing uid heating
Mechanical ltration
Hot air drying
Emergency stop button
Manipulation wheels – lockable
PLC controller + 8,4“ touchscreen display
Spare parts (base kit)
STANDARD HARDWARE EQUIPMENT
Standard software language mutation – CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs – setting option
3 levels of logging – operator, maintenance, engineer
STANDARD SOFTWARE EQUIPMENT
Sonix
®
954 CRD
TECHNICAL DATA SHEET
7
www.dct.cleaning
Standard software language mutation – CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs – setting option
3 levels of logging – operator, maintenance, engineer
OPTIONAL SOFTWARE EQUIPMENT
Automatic rinse uid relling (without pump)
Automatic uids discharging (without pump)
External ltration
Conductivity measurement – rinse 0–2000 µS – blocking optional
Other optional equipment - the complete list of optional accessories will provide you DCT or the local distributor.
OPTIONAL HARDWARE EQUIPMENT
Mechanical basket – folding handle
Mechanical holder for basket
Mechanical basket
OPTIONAL ACCESSORY – FRAMES AND OTHERS
