FUJI IP-QP2 Motor Feeder W32 Parts List KDE-32V0-000246.pdf
1 / 4 機種( M / C TY P E ) ユニット( U N I T) 発行日 I P ・Q P 2 モータフィーダ( M O TO R FEE D ER ) 0 2 . 1 1 . 0 1 形式( TY P E ) 図番( D W G N o . ) S/ N W 3 2 エンボス( E M B O S S) ( A K D FA 6 4 * * ) ( A K D …
1/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 02. 11. 01
形式( TYPE) 図番( DWG No. ) S/N
W32 エンボス( EMBOSS) ( AKDFA64**) ( AKDFA74**) KDE‑ 32V0‑ 000246〜
番
号
品名 図番 個数
No. Dwg. No. QTY
1 ﾎﾝﾀｲ BODY AKDFD6403 1
ﾎﾝﾀｲ BODY KDFD2012 1
ｲﾁｷﾞﾒ POSI TI ONI NG KDCD1022 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｭｱ BEARI NG, MI NI ATURE H4450A 3 LF‑ 1480ZZ( NMB)
ｶﾞｲﾄﾞ GUI DE AKDCD6143 1
ｶﾞｲﾄﾞ GUI DE KDFD1263 1
ﾋﾟﾝ ﾍｲｺｳ PI N, PARALLEL H2092F 1 A4x10SUS303
ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5288A 2 M4x10
ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5290A 1 M4x15
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1022A 3 4M/ M
2 ｵｻｴ RETAI NER KDFC0411 1
3 ｵｻｴ ﾘｰﾙ RETAI NER, REEL KDFC1011 1
4 ｼｬﾌﾄ SHAFT AKDFC6037 1
ｼｬﾌﾄ SHAFT KDFC0095 1
ﾋﾟﾝ ｲﾁｷﾞﾒ PI N, LOCATI NG KDFC0201 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169B 3 M2. 5x4( ﾕﾆｸﾛ)
5 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR AKDFC6211 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDFC0950 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDFC0961 1
6 ｷﾞﾔ GEAR AKDDC6580 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0551 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0152 1
ｼｬﾌﾄ ﾌﾟｰﾘ SHAFT, PULLEY KDDD1090 1
ｷﾞﾔ GEAR KCBC0401 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169B 3 M2. 5x4( ﾕﾆｸﾛ)
7 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR AKDDD6122 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDDD1082 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ BEARI NG, MI NI ATURE H4569A 1 LFｰ630ZZ ( NMB)
8 ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG AKDCC6072 1
ｶﾗｰ COLLAR KCAC0270 1
ｷﾞﾔ ﾋﾟﾆｵﾝ GEAR, PI NI ON KCAC0470 1
ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG KDCC1400 1
9 ｶﾊﾞｰ COVER KDCC1721 1
10 ﾘｰﾙ REEL AKDFC6521 1
ﾘｰﾙ REEL KDFC0921 1
備考
Remarks
Descri pt i on
2/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 02. 11. 01
形式( TYPE) 図番( DWG No. ) S/N
W32 エンボス( EMBOSS) ( AKDFA64**) ( AKDFA74**) KDE‑ 32V0‑ 000246〜
番
号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
ﾏｸﾞﾈｯﾄ MAGNET M1003X 5 丸型ﾈｵｼﾞ磁石φ 5x5
11 ｶﾊﾞｰ COVER KDFC0770 1
12 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDFD1292 1
13 ｼｬﾌﾄ SHAFT AKDFC6076 1
ｼｬﾌﾄ SHAFT KDFC0074 1
ﾋﾟﾝ ｲﾁｷﾞﾒ PI N, LOCATI NG KDFC0201 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0141 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169B 3 M2. 5x4( ﾕﾆｸﾛ)
ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 3 M2. 5x6
ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 3 M2. 5
14 ｶﾞｲﾄﾞﾃｰﾌﾟ GUI DE, TAPE KDFC0041 1
15 ﾋﾟﾝ PI N KDFC0970 2
16 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDCC0101 1
17 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDFD1020 1
18 ｵｻｴ ﾍﾞｱﾘﾝｸﾞ RETAI NER, BEARI NG KDCC1900 1
19 ﾌﾟﾚｰﾄ PLATE KDCC1911 1
20 BKT ﾛｰﾗ BKT ﾛｰﾗ KDFD1280 1
21 ｽﾍﾟｰｻ SPACER S3059H 4 MP‑ 4( ﾏｯｸｴｲﾄ)
22 ﾌﾟﾚｰﾄ PLATE KDCC1680 1
23 ﾋﾟﾝ PI N KDFC0103 1
24 ﾘｰﾙ REEL KDFC0113 1
25 ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0561 1
26 ﾋﾟﾝ PI N KDCC0321 1
27 ﾋﾟﾝ PI N KDDD1100 1
28 ｶﾊﾞｰ COVER KDFC1000 1
29 ﾌﾗﾝｼﾞ FLANGE KDCC0812 1
30 ﾛｰﾗ ROLLER KDDD1111 1
31 ﾌﾞﾛｯｸ BLOCK KDDD1121 1
32 BKT ｾﾝｻ BKT, SENSOR KDFD1103 1
33 ﾋﾟﾝ ｶﾞｲﾄﾞ PI N, GUI DE AKDFD6220 1
ﾋﾟﾝ ｶﾞｲﾄﾞ PI N, GUI DE KDFD1520 1
ﾋﾟﾝ ﾍｲｺｳ PI N, PARALLEL H21155 1 C2x6SUS303
34 ﾚﾊﾞｰ ｸﾗﾝﾌﾟ LEVER, CLAMP KDFD1241 1 ﾓｰﾀ軸ﾌﾞﾚｰｷ( A)
35 ﾚﾊﾞｰ ｸﾗﾝﾌﾟ LEVER, CLAMP KDFD1251 1 ﾓｰﾀ軸ﾌﾞﾚｰｷ( B)
36 ｽﾌﾟﾘﾝｸﾞ SPRI NG KCAC0330 1
3/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 02. 11. 01
形式( TYPE) 図番( DWG No. ) S/N
W32 エンボス( EMBOSS) ( AKDFA64**) ( AKDFA74**) KDE‑ 32V0‑ 000246〜
番
号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
37 ﾋﾟﾝ PI N KDFC0760 2
38 ﾋﾟﾝ PI N KDFD1321 2
39 BKT BKT KDCC1492 1
40 BKT BKT KDCC1501 1
41 BKT ﾓｰﾀ BKT, MOTOR KDDC0200 1
42 ﾌﾟﾚｰﾄｻｲﾄﾞ PLATE, SI DE KDFD1110 1
43 ﾛｰﾗ ROLLER KDFC0980 1
44 ﾊｰﾈｽ HARNESS KHEH1160 1
45 ﾌﾟﾚｰﾄ PLATE KHEM1130 1
46 ﾊｰﾈｽ HARNESS KHEH1251 1 Type6000専用
47 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1091A 1
48 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1108B 1
49 ｼｰﾙ SEAL KHER1120 1
50 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1047E 1
51 ﾊｰﾈｽ HARNESS KHEH1260 1
52 ｽﾌﾟﾘﾝｸﾞ SPRI NG BFCF0060 1
53 ｶﾊﾞｰ COVER KDFC0991 1
54 ﾋﾟﾝ PI N BFCF0281 2
55 ﾋﾟﾝ PI N BFCF0370 1
56 ｸﾘｯﾊﾟ CLI PPER K30164 1 NK‑ 5N ( ｷﾀｶﾞﾜ)
57 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509R 1 344‑ 2GT‑ 12 ( ﾕﾆｯﾀ)
58 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509L 1 340‑ 2GT‑ 2 ( ﾕﾆｯﾀ)
59 ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ PI N, SPRI NG H2050T 1 3x16 AW
60 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 2 2. 5M/M
61 ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K5175S 2 M2x5
62 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020A 2 2M/ M
63 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359E 26 M4x8
64 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5288A 2 M4x10
65 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1022A 7 4M/ M
66 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357M 4 M3x6
67 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5255T 1 M3x6
68 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1021A 13 3M/M
69 ｺﾈｼﾞ SCREW K5158L 2 M2. 5x12 ﾊﾞｲﾝﾄﾞ ｺﾈｼﾞ
70 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1042A 4 4W‑ 3
71 ﾅｯﾄ 6ｶｸ NUT, HEX N1076A 15 M3 P=0. 5
72 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359A 1 M4x6
