Retrofit instructions Approach guard for X trolley on S docking unit SIPLACE HF-series / X-series
03/2005 Edition
15
: Dock the component trolley out of the placement machine.
2
: Use a hammer to tap the approach guard pin into the hole shown in the photograph until it
reaches the stop.
: Fit the approach guard on both sides of the docking unit.
2
the left of two holes 2
Tap in the approach guard 2
Approach guard fitted 2
Component trolley stops
at the approach guard 2
