3 / 5 機種( M / C TY P E) ユニット( U N I T ) 発行日 I P ・Q P 2 モータ フィーダ( M O TO R FE E D E R ) 0 0 . 1 0 . 2 7 形式( TY P E) 図番( D W G N o . ) S / N W 7 2 エンボス( E M B O S S) ( A K D J A 7 1 * * ) K D E…
2/5
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータ フィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W72 エンボス( EMBOSS) ( AKDJ A71**) KDE‑ 7200‑ 000293〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
ﾏｸﾞﾈｯﾄ MAGNET M1003X 5 丸型ﾈｵｼﾞ磁石φ 5x5
11 ｶﾊﾞｰ COVER KDJ C1050 1
12 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE AKDCC6531 1
ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0821 1
ﾋﾟﾝ ｼﾃﾝ PI N, PI VOT KCAC0420 2
13 ｼｬﾌﾄ SHAFT AKDJ C6034 1
ｼｬﾌﾄ SHAFT KDJ C0073 1
ﾋﾟﾝ ｲﾁｷﾞﾒ PI N, LOCATI NG KDFC0201 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0141 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/ R COUNTERSUNK K5169D 3 M2. 5x4
ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 3 M2. 5x6
ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 3 M2. 5
14 ｶﾞｲﾄﾞﾃｰﾌﾟ GUI DE, TAPE KDJ C0042 1
15 ｼｬﾌﾄ SHAFT KDJ C0051 2
16 ﾛｰﾗ ROLLER KDJ C0060 1
17 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDCC0100 1
18 ﾜｯｼｬ WASHER KDCC0111 3
19 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0124 1
20 ｵｻｴ ﾍﾞｱﾘﾝｸﾞ RETAI NER, BEARI NG KDJ C1040 1
21 ﾌﾟﾚｰﾄ PLATE KDCC0742 1
22 ﾌﾟﾚｰﾄ PLATE AKDCC6550 1
ﾌﾟﾚｰﾄ PLATE KDCC1420 1
ﾌﾟﾚｰﾄ PLATE KDCC1340 1
23 ﾚﾊﾞｰ LEVER KDCC0190 1
24 ﾋﾟﾝ PI N KDCC0201 1
25 ｽﾍﾟｰｻ SPACER KDCC0231 4
26 ﾌﾟﾚｰﾄ PLATE KDCC0251 1
27 ﾋﾟﾝ PI N KDFC0103 1
28 ﾛｰﾗ ROLLER KDJ C0090 1
29 ﾘｰﾙ REEL KDFC0113 1
30 ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0561 1
31 ﾋﾟﾝ PI N KDCC0321 1
32 ﾋﾟﾝ PI N KDDC0171 2
33 ﾛｰﾗ ROLLER KDDC0180 1
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
3/5
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータ フィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W72 エンボス( EMBOSS) ( AKDJ A71**) KDE‑ 7200‑ 000293〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
34 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDDC0250 1
35 ｶﾊﾞｰ COVER KDCC0732 1
36 ﾌﾗﾝｼﾞ FLANGE KDCC0811 1
37 ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0223 1
38 ﾌﾞﾛｯｸ BLOCK KDGC0140 1
39 BKT ｾﾝｻ BKT, SENSOR KDCC0591 1
40 ﾋﾟﾝ ﾍﾝｼﾝ PI N, ECCENTRI C KDCC0601 1
41 ﾚﾊﾞｰ ｸﾗﾝﾌﾟ LEVER, CLAMP KCAC0310 1 ﾓｰﾀ軸ﾌﾞﾚｰｷ( A)
42 ﾚﾊﾞｰ ｸﾗﾝﾌﾟ LEVER, CLAMP KCAC0320 1 ﾓｰﾀ軸ﾌﾞﾚｰｷ( B)
43 ｽﾌﾟﾘﾝｸﾞ SPRI NG KCAC0330 1
44 ﾋﾟﾝ PI N KDFC0760 2
46 ｵｻｴ RETAI NER KCAC0430 1
47 BKT BKT KDCC1491 1
48 BKT BKT KDCC1501 1
49 ﾋﾟﾝ PI N KCBC0681 1
50 ﾒｲﾊﾞﾝ NAME PLATE KDJ C0083 1
51 BKT ﾓｰﾀ BKT, MOTOR KDDC0200 1
52 ﾌﾟﾚｰﾄｻｲﾄﾞ PLATE, SI DE KDFC0220 1
55 ﾊｰﾈｽ HARNESS KHEH1240 1
56 ﾌﾟﾚｰﾄ PLATE KHEM1130 1
57 ﾊｰﾈｽ HARNESS KHEH1290 1
58 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1091A 1
59 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1108A 1
60 ｼｰﾙ SEAL KHER1120 1
62 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1047E 1
63 ﾊｰﾈｽ HARNESS KHEH1260 1
64 ｽﾌﾟﾘﾝｸﾞ SPRI NG BFCF0060 1
65 ｶﾊﾞｰ COVER KDJ C0720 1
66 ﾋﾟﾝ PI N KDJ C0130 1
67 ﾋﾟﾝ PI N KDJ C0191 1
68 ｸﾘｯﾊﾟ CLI PPER K3015H 1 SL‑ 3N ( 品川商工)
69 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509R 1 344‑ 2GT‑ 12 ( ﾕﾆｯﾀ)
70 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509L 1 340‑ 2GT‑ 2 ( ﾕﾆｯﾀ)
71 ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ PI N, SPRI NG H2050T 1 3x16 AW
72 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 2 2. 5M/M
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
4/5
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータ フィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W72 エンボス( EMBOSS) ( AKDJ A71**) KDE‑ 7200‑ 000293〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
73 ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K5175S 2 M2x5
74 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020A 2 2M/ M
75 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359E 31 M4x8
76 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5255T 3 M3x6
77 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5289A 2 M4x12
78 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1022A 6 4M/ M
79 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357M 13 M3x6
80 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5256A 4 M3x8
81 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1021A 10 3M/ M
82 ｺﾈｼﾞ SCREW K5168L 2 M2. 5x10 ﾊﾞｲﾝﾄﾞ ｺﾈｼﾞ
83 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1042A 2 4W‑ 3
84 ﾅｯﾄ 6ｶｸ NUT, HEX N1076A 11 M3 P=0. 5
85 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359A 2 M4x6
86 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357T 4 M3x8
88 ﾅｯﾄ 6ｶｸ NUT, HEX N1075A 2 M2. 5
89 ﾅｯﾄ 6ｶｸ NUT, HEX N1080A 4 M4
90 ｻｰｸﾘｯﾌﾟ CI R‑ CLI P S1021A 1 STｰEWｰ3
91 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357G 2 M3x4
92 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1041A 3 M4
94 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K52565 1 M4x6
95 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5358A 6 M3x10
96 ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/ R COUNTERSUNK K5169D 3 M2. 5x4
97 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET K5273A 1 M3x5
99 ｼｰﾄ SHEET KHEM1081 1
100 ｼｰﾙ SEAL KDJ C0210 1
101 ｽﾄｯﾊﾟ STOPPER KDFC0280 1
102 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1039D 2 2mm x0. 3 x5 ( ﾐｶﾞｷ丸)
103 ｼｬﾌﾄ SHAFT KDJ C0141 1
104 ﾛｰﾗ ROLLER KDJ C0200 1
106 ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 2 M2. 5x6
107 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1039H 6 M2. 5
108 ｼｰﾄ SHEET KDCC1280 1
109 SW SW S3087S 1
110 ﾌﾟﾚｰﾄ PLATE KDCC1221 1
111 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5277A 7 M3X12
