SMART-SIZED HIGH SPEED DISPENSER V ersatile, Accurat e, Artistic & Reliable
SMART-SIZED HIGH
SPEED DISPENSER
Versatile, Accurate, Artistic & Reliable
SMART-SIZED HIGH
SPEED DISPENSER
Introducing - The Spider - State of the
art technology, easily integrated in any
line.
l
Up to 2 valves simultaneously
l
5 different valves, large application range
l
Up to 150’000 dots/h (with Piezo Jet Valve)
l
Up to 2’000’000 dot/h line mode
l
Requires only 1 m² of production loor
l
Machine its through 90 cm wide door
l
No vibration, symmetrical mineral casting
l
No warpage, no thermal drift
l
Mapping of heights using laser technology
l
Compensation of substrate warp / 3D contour
CELL SOLUTION
LINE SOLUTION
l
Fast, reliable double drive linear motors
l
No maintenance, longest lifetime
dispense technology.
productivity
.
small footprint.
mineral cast.
laser height mapping.
linear motors.
MULTITALENT SOFTWARE AT YOUR FINGERTIPS State of the art, full graphics,
21.5”, 16:9 HD wide touch screen, ingertip operation, universal CAD conversion,
Windows 10 - 64 bit, zoom at camera windows, all-in-one job planning, setup
optimisation, easy deinition of pattern and assistant process support
Valves & Pumps
Media Heating
Needle and jet heating system
Level Detection Automatic syringe level detection
Process Control Process control adjustment & stabilization
Vacuum Cleaning Station, High Precision Scale, Clean Room, Heating/Vacuum Table
Full process control meeting automotive standards and more
Wide range of dispensing applications such as
Solder Paste and SMT Glue, LED Encapsulation,
Silver Epoxy, Dam and Fill, Underill, Cavity Fill,
3D Dispensing via laser height mapping and more
Full operator support - Automated error analysis
& KPI. Training, support and troubleshooting via
advanced remote access. Investment protection;
all options and heads retroittable.
Two processes at the same time. Plug and Play for
valve change. Piezo Jet Valve - super high speed for
low viscosity. Solder Jet, Volume Displacement,
Time/Pressure, Archimedean Screw Valve
INTEGRATE INTO HIGH SPEED
LINES AND HIGHLY COMPLEX
DISPENSE APPLICATIONS
