Proc ess Max. dispensing speed Piezo Jet: 150‘000 dots/h T ime/Pr essur e: 28‘000 dots /h Pneumatic Jet: 80‘000 dots /h Archimedean Scr ew: 24‘000 dots/h Dispensing mode Dot , line, curve, interpolated 3D contour Accurac…
SMART-SIZED HIGH
SPEED DISPENSER
Introducing - The Spider - State of the
art technology, easily integrated in any
line.
l
Up to 2 valves simultaneously
l
5 different valves, large application range
l
Up to 150’000 dots/h (with Piezo Jet Valve)
l
Up to 2’000’000 dot/h line mode
l
Requires only 1 m² of production loor
l
Machine its through 90 cm wide door
l
No vibration, symmetrical mineral casting
l
No warpage, no thermal drift
l
Mapping of heights using laser technology
l
Compensation of substrate warp / 3D contour
CELL SOLUTION
LINE SOLUTION
l
Fast, reliable double drive linear motors
l
No maintenance, longest lifetime
dispense technology.
productivity
.
small footprint.
mineral cast.
laser height mapping.
linear motors.
MULTITALENT SOFTWARE AT YOUR FINGERTIPS State of the art, full graphics,
21.5”, 16:9 HD wide touch screen, ingertip operation, universal CAD conversion,
Windows 10 - 64 bit, zoom at camera windows, all-in-one job planning, setup
optimisation, easy deinition of pattern and assistant process support
Valves & Pumps
Media Heating
Needle and jet heating system
Level Detection Automatic syringe level detection
Process Control Process control adjustment & stabilization
Vacuum Cleaning Station, High Precision Scale, Clean Room, Heating/Vacuum Table
Full process control meeting automotive standards and more
Wide range of dispensing applications such as
Solder Paste and SMT Glue, LED Encapsulation,
Silver Epoxy, Dam and Fill, Underill, Cavity Fill,
3D Dispensing via laser height mapping and more
Full operator support - Automated error analysis
& KPI. Training, support and troubleshooting via
advanced remote access. Investment protection;
all options and heads retroittable.
Two processes at the same time. Plug and Play for
valve change. Piezo Jet Valve - super high speed for
low viscosity. Solder Jet, Volume Displacement,
Time/Pressure, Archimedean Screw Valve
INTEGRATE INTO HIGH SPEED
LINES AND HIGHLY COMPLEX
DISPENSE APPLICATIONS
Process Max. dispensing speed Piezo Jet: 150‘000 dots/h Time/Pressure: 28‘000 dots/h
Pneumatic Jet: 80‘000 dots/h Archimedean Screw: 24‘000 dots/h
Dispensing mode Dot, line, curve, interpolated 3D contour
Accuracy Placement XY dots 40 µm (3σ)
Positioning Z axis 20 µm (3σ)
PCB PCB dimensions 50 x 50 mm up to 406 x 305 mm (2 x 2” up to 16 x 12”)
Dimensions Machine footprint 880 x 1090 mm (34.7 x 43”)
Essemtec AG
Mosenstrasse 20
CH-6287 Aesch/LU
Switzerland
FLEXIBLE SMT
SOLUTIONS
CHOOSE YOUR
PREFERENCES
Phone: +41 (0)41 919 60 60
Fax: +41 (0)41 919 60 50
Mail: info@essemtec.com
Wildlife consistently shows us with breathtaking flexibility how nature can
adapt itself to the many dierent demands of its environment; that is what
inspires us! Essemtec AG is a privately owned company with its development
and production site in Switzerland. The product portfolio comprises of pro-
duction equipment for electronic assembly and more. Our high tech solu-
tions can be adjusted quickly and easily to meet wide ranging requirements;
we are therefore able to respond to all manner of customer requests. That’s
why “naturally adaptive” is our motto across all ranges.
Disclaimer & Copyright:
The information contained in this brochure is for general information purpo-
ses only. For more information see the specification sheet. All materials con-
tained in this brochure are copyright © Essemtec AG, Switzerland, May 2017
