iv 为了安全使用 KE-2070/80/80R 的注意事项 1.为了防止触电引起的事故，请勿在接通电源的状态下 打开电气设备箱。 2.为防止触电，请勿在拆下接地线的状态下运行。 1.为防止人身受伤，请勿在拆下安全罩、安全装置等状 态下运行。 2.为防止人身受伤，请务必小心，以免头发、衣服等被 卷入传送带链。 此外，请勿戴手套。 3.为防止人身受伤，维护时（加油、调试、日常检修） ，请切断电源。 4.为防止人身受伤，请在电源线上使用漏电…
iii
注意（续）
各使用环节中的注意事项
搬 运
1. 为防止提起、移动时发生颠倒、掉落事故，请采取充分的安全对策。
2. 请在下述环境下运输及保管
环境条件 温度 ：-15℃～70℃
湿度 ：20％～95％RH (但不得有露水)
开 封
1. 请阅读装运用集装箱内所述的所有指示。
2. 包装带绝不能用刀割开。
3. 请保管好装运用的器材。
安 装
1. 为避免正在运行的机器意外移动引起事故，请用高度调节装置，将滚动轮悬起。
2. 请将本机器设置在水平的地方。
3. 为防止触电、漏电、火灾，电缆类请使用配套附件，并连接在规定的位置。
4. 为防止触电、漏电、火灾，在运行时，电缆请勿过度加压。
5. 电源插头、I/F 电缆的连接器，请固定到位。在拔出电源插头、I/F 电缆时，要握住连接器部拔出。
运行前
1. 为了防止人身事故，在接通电源前，请确认连接器、电缆类无损伤、脱落、松弛等。
2. 为了防止人身事故，请勿将手放入驱动部。
3. 在驱动气缸下面注意不要放工具或其他物品。否则在送料器台架下降时与驱动气缸接触，不仅会损伤
放置的东西，还会损坏机器或连接器部，也有引起短路发生火灾的危险。
加 油
1. 润滑脂请使用 JUKI 指定的润滑脂。
2. 为了防止炎症、斑疹，润滑脂附着在眼睛里或身体上时，请立即进行清洗。
3. 误食时，为防止腹泻、呕吐，请立即请医生诊断。
维 护
1. 为了防止因操作不熟悉而引起的事故，修理、调试作业应由熟悉机械的保全技术员进行。更换零部件
时，请使用本公司的纯正部件。对使用非纯正部件所引起的事故，本公司概不负责。
2. 为了防止操作不熟练而引起的事故和触电事故，有关电气的修理、保全（包括配线），请委托有电气
专业知识的人员或本公司、销售公司的技术人员。
3. 为防止意外起动造成事故，请拆下气源管，放出剩余的空气后再进行维护。
4. 为防止人身事故，进行修理调试、零部件更换等作业后，请确认螺钉、螺母等稳固不松弛。
使用环境
1. 为防止因错误操作而引起的事故，请勿在受高频焊机等干扰源（电磁波）影响的环境下使用。
2. 为防止因错误操作而引起的事故，请勿在电源电压超过额定电压±10％的情况下使用。
3. 为防止因错误操作而引起的事故，请在 0.5±0.05MPa 的供气压力下使用。
4. 为了安全使用，请在下述环境下使用。
运行的环境条件 温度 ：10℃～35℃
湿度 ：30％～80％RH (但不得有露水)
标高 ：1,000m 以下
5. 为防止电气部件破损引起的事故，从冷处将机器突然移动到暖处时，有时会结露，因此，请在完全无
需担心水滴后再接通电源。
6. 为防止电气部件破损而引起的事故，打雷时，请停止使用，并拔出电源插头。
注意
iv
为了安全使用 KE-2070/80/80R 的注意事项
1.为了防止触电引起的事故，请勿在接通电源的状态下打开电气设备箱。
2.为防止触电，请勿在拆下接地线的状态下运行。
1.为防止人身受伤，请勿在拆下安全罩、安全装置等状态下运行。
2.为防止人身受伤，请务必小心，以免头发、衣服等被卷入传送带链。
此外，请勿戴手套。
3.为防止人身受伤，维护时（加油、调试、日常检修），请切断电源。
4.为防止人身受伤，请在电源线上使用漏电断路器。
1.本装置的操作系统采用 Windows XP（包括以太网通信功能）。
除安装本装置提供的软件之外，加装其他软件，不保证正常运行。对 HDD 内组装的文件
进行转移、重命名、文件夹·文件的压缩、复制，也同样不保证正常运行，敬请谅解。
●万一出现此钟情况，需要更换新的 SSD 或 HDD，有可能丢失数据，务请格外注意。
为保护操作系统，使用了 Enhanced Write Filter(EWF)组件，进行了 C 盘 ROM 化。
1.请不要在 C 盘保存文件。
把文件保存在 ROM 化后的 C 盘，会仿真占用主存储器。因而，把文件存在 C 盘里时，
会增加主存储器的使用量，压迫系统。反复保存后可能造成内存不足，显示系统错误，
可能需要重启本设备。
2.需要修改 OS 信息时，必须刷新 C 盘操作。操作方法请参见使用说明书「1－6 更新 C 盘
的操作」。
需要修改 OS 信息的操作是指下列事项：
·KE-2070/80/80R 系统软件、FlexLine DB 的版本升级
·触摸屏自我校正
·添加打印机
·设置网络（IP 地址、工作组等）
·添加用户
·变更资源管理器的设置
·变更 UPS 实用程序（UPSilon2000）的设置
●要变更操作系统信息时，在修改 C 盘操作后，需要重启一次本装置。
1.本装置配备有 UPS，以保护停电时的生产程序等。
为防止 UPS 内置电池劣化，请勿在非通电状态下将本装置放置 6 个月以上。
●本装置以电流总断路器及总开关 ON 的状态为通电状态。
〈安全盖〉
1.开关安全盖时请注意下列事项。
·打开安全盖时要把盖子向上开足直到上了锁，确认上了锁后再放开手。没有上好锁就
放开手时，盖子有落下来的危险。
·关盖子时先解开锁，再关闭盖子。
（请注意，解开锁时不要使盖子落下来导致受伤。）
·不要过渡增加盖子、手把等的负荷。
1.安装等时请不要站到机器上面，以免损坏外罩类。
危险
注意
注意
注意
注意
注意
注意
操作手册 II 目录
为了安全使用机器
目录
第 1 章 设备概要···································································································· 1-1
1-1 前言 ··························································································································· 1-1
1-2 特点 ··························································································································· 1-1
1-3 系统构成···················································································································· 1-4
1-3-1 KE-2070 系统构成····························································································· 1-4
1-3-2 KE-2070C 系统构成 ························································································· 1-5
1-3-3 KE-2080 系统构成····························································································· 1-6
1-3-4 KE-2080R 系统构成·························································································· 1-7
1-4 设备概要···················································································································· 1-8
1-4-1 本设备的构成 ··································································································· 1-8
1-4-1-1 贴片头单元的构成 ················································································· 1-10
1-4-1-2 ATC 单元(Auto Tool Changer 自动工具交换)的构成····························· 1-11
1-4-1-3 吸嘴 ······································································································ 1-12
1-4-1-4 OCC 的构成··························································································· 1-13
1-4-1-5 VCS 的构造 ··························································································· 1-14
1-4-1-6 HMS ······································································································ 1-15
1-4-2 机器规格········································································································· 1-16
1-4-3 对象元件及元件包装方式················································································ 1-18
1-4-4 印刷基板规格 ································································································· 1-20
1-4-5 定心系统········································································································· 1-24
1-4-6 X,Y,Z,θ 轴的说明····························································································· 1-25
1-5 菜单的构成 ·············································································································· 1-26
1-6 通过模式·················································································································· 1-30
1-7 文件操作·················································································································· 1-31
1-7-1 新建················································································································ 1-31
1-7-2 打开（读入文件） ·························································································· 1-31
1-7-3 保存················································································································ 1-32
1-7-4 另存为 ············································································································ 1-32
1-7-5 文件管理········································································································· 1-32
1-7-6 生产程序初始位置
·························································································· 1-33
1-7-
7 设置打印机 ····································································································· 1-33
1-7-8 打印················································································································ 1-33
1-7-9 控制数据管理、设备信息的保存、保存图像数据············································ 1-33
1-7-10 硬件安全拆卸 ······························································································· 1-33
1-7-11 C 盘的更新操作····························································································· 1-34
第 2 章 制作生产程序····························································································· 2-1
2-1 流程图 ······················································································································· 2-1
2-2 选项 ··························································································································· 2-2
2-2-1 用户组 ·············································································································· 2-2
2-2-1-1 变更用户组······························································································ 2-2
2-2-1-2 设置用户组环境······················································································· 2-3
2-2-2 设置用户组环境································································································ 2-3
2-3 制作生产程序············································································································· 2-4
2-3-1 启动生产程序编辑 ···························································································· 2-4
2-3-2 生产程序的制作步骤························································································· 2-4
2-3-3 基板数据··········································································································· 2-5
2-3-3-1 基本设置 ································································································· 2-5
2-3-3-2 尺寸设置 ································································································· 2-8
