THE HARDWARE: ASM ProcessLens
The core component of the ASM ProcessExpert is the
ASM ProcessLens 5D inline SPI system. Instead of operating
with rigid piezo-controlled grids, this high-precision, extremely
fast SPI system is fully digital and generates the Moiré pattern
projections needed to measure the solder paste deposits exibly,
precisely and extremely quickly via a projector chip with 8 million
individually controllable micro-mirrors.
Other advantages include combined 2D/3D measurements, an
X/Y camera positioning system with an accuracy of 12.5 µm, mul-
tiple light sources for shadow-free measurements, 3D-on-the-y
compensation of board warpage, and extremely powerful image
analysis algorithms.
The bottom line: The ASM ProcessLens detects the position,
height, area and volume of solder deposits as well as any PCB
warpage faster and more accurately than traditional SPI systems.
THE SOFTWARE: ASM ProcessEngine
The system combines the measurement data collected by the
ASM ProcessLens with all relevant printing process parameters
and stores them in the database of the ASM ProcessEngine
expert system software. This software learns with each printing
cycle, identies trends and determines corrective measures to
keep the printing process stable within its process window at all
times. The ASM ProcessEngine can output its corrective measu-
res as assist requests or set the new printing parameters directly
on the printer with no human interaction.
FROM SPI TO EXPERT SYSTEM
Thanks to its modular structure, the
ASM ProcessExpert features maximum
investment protection. You can start out with the
ASM ProcessLens as a powerful SPI system and
add the ASM ProcessEngine software later to
expand it into a full-featured expert system.
ASM ProcessExpert
THE MODULAR SYSTEM FOR MAXIMUM
INVESTMENT PROTECTION
ASM ProcessExpert
Expert system
ASM ProcessLens
SPI
ASM ProcessEngine
Software
6
ASM ProcessExpert
THE MODULAR SYSTEM FOR MAXIMUM
INVESTMENT PROTECTION
ASM ProcessLens
TECHNICAL DATA
ASM ProcessLens coverage area
Length – in PCB conveyor direction 1,130 mm
Width 1,300 mm
Height with a conveyor height of 950 mm 1,600 mm
ASM ProcessLens transport
Duration of loading/unloading – single conveyor
Duration of loading/unloading – dual conveyor
Less than 2.5 sec.
0 sec.
Transport height/interface SMEMA, IPC-HERMES-9582
ASM ProcessLens PCB
PCB size (L x W) – single conveyor
PCB size (L x W) – dual conveyor (standard)
PCB size (L x W) – dual conveyor (in single-conveyor mode)
Minimum Maximum
50 mm × 50 mm 610 mm × 560 mm
50 mm × 45 mm 375 mm × 260 mm
50 mm × 45 mm 375 mm × 460 mm
PCB thickness 0.5 mm to 4.5 mm
Minimum edge clearance 3 mm
Maximum PCB weight 3 kg
PCB warpage -7.5 mm to +7.5 mm
ASM ProcessLens inspection values
Pixel size 15 μm × 15 μm
Inspection speed Up to 30 cm
2
/sec
Height resolution 0.37 μm
Height accuracy with calibration target ≤ 1 μm
X/Y gantry accuracy ± 12.5 μm (at ± 3σ)
ASM ProcessLens solder paste inspection
Measurement Shadow-free
Solder paste measurements
Volume, area, height, X- and Y-offset,
shape, bridging, coplanarity
Maximum paste height 1,000 μm
Minimum paste deposit size 90 μm × 130 μm
GRR on printed board << 10%
7
