Installation Manual SIPLACE EDM 1.7 Edition05/2009
3.2 Forced pull mode
In order to have some influence on this situation, SIPLACE Pro provides the “forced pull mode”. This
mode allows for the specification of a maximum time period between two downloads. This should
ensure that the data on the lines is never older than the prescribed time period. If no data is
downloaded from the master server during the time period defined, then the data preparation
engineer is informed of this via a SIPLACE EDM notification and can initiate organizational activities
to ensure the data is downloaded and up-to-date.
Installation Manual SIPLACE EDM 1.7 Edition 05/2009
4 Installation
4.1 Requirements
4.1.1 EDM master server
Minimum Requirements
Hardware Intel Pentium 4, 3 GHz
2 GB RAM
1 GB hard disk space
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3 or Windows
Vista SP1
MSMQ runtime must be installed
SIPLACE Pro 7.0 server installation
Microsoft SQL Server Preferred: SQL Server 2008, SQL Server 2008 Express Edition
Supported: SQL2000 SP 4, MSDE 2000 SP4, SQL Server 2005 SP3, SQL
Server 2005 Express SP3
.NET Framework Microsoft .NET 3.5 SP 1
Table 1 EDM master server software requirements
Caution:
When updating to the SQL Server 2005 (Express), the service jobs which are created
manually, can be lost.
11 of 66
Installation Manual SIPLACE EDM 1.7 Edition05/2009
4.1.2 EDM line server
Minimum Requirements
Hardware Intel Pentium 4
1 GB RAM
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3 or Windows
Vista SP1
MSMQ runtime must be installed
SIPLACE Pro 7.0 complete installation
Microsoft SQL Server Preferred: SQL Server 2008, SQL Server 2008 Express Edition
Supported: SQL2000 SP 4, MSDE 2000 SP4, SQL Server 2005 SP3, SQL
Server 2005 Express SP3
.NET Framework Microsoft .NET 3.5 SP 1
Table 2 EDM line server software requirements
4.1.3 Clearing pool
Minimum Requirements
Hardware Intel Celeron 1.7 GHz
512 MB RAM
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3 or Windows
Vista SP1
MSMQ runtime must be installed
SIPLACE Pro SIPLACE Pro Desk 7.0
Table 3 Clearing pool software requirements
Attention:
Before installing a ClearingPool on your local PC, that has access to a remote EDM master,
you must install SIPLACE Pro Desk on your local system. Thereby, SIPLACE Pro Desk must
also have access to the remote EDM Master.
